XRAY 320203 - Xray T2D 2019 - 2WD 1/10 Electric Stadium Truck - Dirt Edition  [XR-320203]

XRAY XT2
1/10 DELUXE STADIUM TRUCK 2WD

2018 All-new

• Recent EOS Champion and united states Champion platform
• All-in-one concept  includes specific elements to create the XT2 for particular track conditions on either Carpet or Dirt:

- Both types of gearboxes and engine meals enabling placement related to engine in paid down position (Carpet) or top place (Dirt)

- Gear differential (carpeting) and ball differential (dust)

- Two different hardness of suspension system hands: medium (Dirt), difficult (Carpet)

- Two various backside shock towers: composite (carpeting), graphite (Dirt)

- Both forms of composite battery pack straps to fit two different gear containers

- Both types of composite mounts for upper brace to suit two different gear containers

- Composite gear cover to shield kit package from dust

• Brand New smaller front composite framework front side brace enables mounting of new graphite component guard brace to modify front chassis flex
• New graphite framework part guard brace for increased security and performance
• New protected steering linkage mounting increases dependability from the steering assembly
• New surprise absorber reduced shims offer more accurate shock shaft movement
• New shock absorber O-rings for better sealing and shock performance
• New suspension system pin washers prevent the suspension pins from hitting theaters, increasing dependability

General

• Recent EOS Champion and USA Champion platform
• All-in-one concept  includes particular components to create the XT2 for specific track conditions on either Carpet or Dirt:
• Both forms of gearboxes and motor meals enabling positioning regarding the engine in lower place (Carpet version) or top place (Dirt Edition)
• Gear differential (carpeting Edition) and ball differential (Dirt version) included
• Based on ultra-successful XB2 platform
• Full compatibility and interchangeable parts
• Designed for highest performance at all degrees of racing
• Engineered with knowing of smallest details
• Manufactured with prominent imaginative craftsmanship from premium European materials
• EFRA, ROAR, FEMCA spec compliant
• Super a simple task to construct, set up, maintain, and drive
• Developed, created, and styled by European Champion Martin Bayer and Dipl. Eng. Juraj Hudy, produced entirely by XRAY in Countries In Europe on planet's most advanced RC manufacturing facility
• Setting the modern standard for premium quality, dependability and performance
• Premium XRAY solution & support

Chassis

• Optimal framework fat blood circulation & balance
• Both kinds of gearboxes and engine plates permitting keeping of this engine in reduced destination (carpeting Edition) or top position (Dirt Edition)Original XRAY Multi-Flex™ technology for easy framework flex adjustment
• Swiss 7075 T6 hardcoated 2.0mm aluminum framework: lightweight, strong, rigid
• Electronics design allows going the batteries frontwards/rearwards, and utilizing standard or mid-size servos and either utilizing seat pack or short pack batteries
• Composite part guards are an integral part of the XT2 Multi-Flex™ system
• Shorter front composite chassis front brace allows mounting of new graphite side guard brace to modify front chassis flex
• Custom-designed front lower framework brace, available in moderate and difficult hardness for particular track conditions
• Front security bumper
• Custom-designed top deck, obtainable in moderate and hard hardness for particular track conditions
• Swiss 7075 T6 aluminum engine plate
• Both kinds of composite battery straps to fit two different gear bins with foam spacer
• Lightweight, strong composite shock towers with many surprise mounting jobs (carpeting Edition) & graphite rear shock tower (Dirt Edition)
• Pre-drilled centerline holes for easy balancing because of the HUDY Chassis Balancing Tool #107880

Drivetrain & Differentials:

• Conventional gear-driven 2WD off-road arena truck
• Unique gear box, Gear Box and engine Plate with lowered top shaft, forward-shifted motor for improved steering and handling on higher-traction surfaces
• Included rear gear differential with adjustable oil viscosity, 53T gear & interior satellite gears (Carpet Edition)
• Included externally-adjustable ball differential, 53T gear & axial bearings (Dirt Edition)36T (carpeting Edition) & 25T (dust Edition) graphite composite idler gears
• 20T super-lightweight Swiss 7075 T6 hardcoated aluminum top shaft
• Robust slip-adjustable clutch with 81T primary spur gear molded from exclusive secret combination of composite material
• 3-pad slipper clutch with ultra-efficient SLS product for more efficient & exact slip modification, and HUDY Spring Steel™ hardened outdrives for extra lifespan and reliability
• Constant velocity drives (CVD) are manufactured from unique HUDY Spring Steel™ for paid off weight and increased durability
• Ultra-lightweight 12mm wheel hex drive hubs CNC-machined from Swiss 7075 T6 and also black-coated have ultra-true hex clamping design which guarantees solid mounting of wheel
• Full pair of 22 high-speed, blue-sealed ball-bearings are utilized through drivetrain to be sure maximum efficiency, degreased and oiled with AeroShell® Fluid 12 for optimum smoothness and endurance

Suspension

• Integrated Suspension Settings (I.S.S.) for quick & effortless suspension system geometry establishing utilizing eccentric bushings placed into Swiss 7075 T6 aluminum suspension system holders
• Specially-designed suspension system elements made of cautiously developed personalized composite mixtures to ensure appropriate flex and durability
• Race-perfected suspension geometry for superior performance and versatility in many competition conditions.
• Suspension arms can be found in moderate, hard and graphite hardness for particular track conditions
• Suspension components: steering blocks, caster obstructs and uprights are located in medium and hard hardness for specific track conditions
• Lower composite supply install with integral 26° kick-up angle; optional aluminum and metal supply mounts available
• Lightweight, rigid caster obstructs is able to do different basic caster angles using included caster bushings
• Tiny yet tough steering obstructs made up of composite steering obstructs + graphite Ackermann extensions
• Adjustable fat balance & wheelbase via included shims on exterior suspension system pins
• Compact back uprights with 0° toe and 6 different top roll center positions
• HUDY Spring Steel™ item for turnbuckles (featuring a tougher core) is employed for front side & rear upright linkages, and steering system.
• Front anti-roll club constructed from special spring metal product to support the car at front side is installed towards leading human body mount & can be simply modified via linkages; laser-engraved markings for simple identification, obtainable in different sizes for fine-tuning
• Optionally available straight back anti-roll bar set to aid a corner associated with automobile; effortlessly modified via linkages; laser-engraved markings for simple identification, for sale in various sizes for fine-tuning
• Suspension pin washers stop the suspension system pins from coming out, increasing dependability

Steering

• Simple yet effective dual-arm steering system
• Secure steering linkage mounting increases dependability of steering assembly
• Fully bearing-equipped with 8 high-speed ball-bearings for very precise steering
• Easily-adjustable Ackermann by fast changing the steering link mounting jobs regarding steering plate
• Bump guide modification for much more aggression
• Ackermann modification via included shims or utilizing different graphite expansion dishes on steering blocks

Shocks

• constant, dependable, membrane-free shocks with bleed-screw shock restriction design function up-stop & downstop adjustment via shims (under surprise collar, and under pistons, correspondingly)
• Swiss 7075 T6 aluminum shock systems, paid off nut & bleeder shock caps
• Super-precise molded Delrin™ pistons can be obtained with 2-hole & different diameters (1.6mm & 1.7mm) for precise surprise modification, for customized modification, an accumulation blank pistons (no holes) will also be included
• Shock rods are machined from a particular steel product, accuracy hand-ground for maximum smooth operation and also hardened for increased lifespan
• Premium surprise springs designed especially to fit the XT2 shocks; by hand calculated, selected and matched into pairs to ensure equal size and damping characteristics; laser etched for easy identification
• Full style of linear -or- modern surprise springs available
• Premium silicone natural oils laboratory tested and calibrated to make sure maximum persistence and quality

Body, Wings, Wheels:

• High-downforce, low-profile aerodynamic Lexan™ human body made to completely fit the XT2, features high-downforce areas (including front display screen and top roof movement channels) for appropriate venting, and component downforce areas for greater security.
• Tough composite part guards work double-sided Velcro™ tape to seal the human body entirely towards chassis and seal against dirt.
• Effective back wing wound up being made to work entirely utilising the XRAY XT2 body. Produced from strong Lexan™ material, the wing is supported on wing mounts by additional flat shims to higher help and expand living about the wing.
• Specially produced 12mm hex hub tires for high-competition competition; featuring reinforcement ribs to eliminate deformation and molded from actually flexible material to retain form even with impacts (available as choice simply)

Assembly, Set-up & Support:

• Premium 3D full-color guide & supplementary sheets
• To completely understand the set-up opportunities we recommend the popular HUDY Set-up Book which can be packed with over 40 pages of top-notch pictures and easy-to-read RC car set-up explanations
• Exclusive Virtual online Setup Sheet database with and endless choice of set-up sheets for battle songs across the world
• Premium, unmatched XRAY on the web support

Adjustment possibilities:

• Fully-adjustable front part and back suspension system system geometry: caster, camber, right back toe, kick-up, anti-squat, ride height, downstops, track-width, roll center, wheelbase, Multi-Flex™
• Adjustable back differential action
• Adjustable slipper clutch
• Adjustable HUDY Sprint Steel™ turnbuckles (steering, front & back upper links)
• several upper & paid off shock mounting locations at front & rear
• Adjustable Ackermann and bumpsteer
• Adjustable front part anti-roll bar
• Optional adjustable backside anti-roll bar
• Chassis pre-drilled holes for fat security modification
