In 2019 the planet's hottest mini RC series, known as the Kyosho MINI-Z, celebrated above 2 decades of unmatched performance and scale realism in to the hobby-grade RC category. The constant look for performance and development has generated the creation of a completely-new ‘MINI-Z 4x4’ design that provides an all-new driving experience for RC fans of stripes, with superior basic design, driving performance and top-quality injection-molded scale human body construction. An important purpose of the MINI-Z 4x4 show could be the greater emphasis of human body information and quality of finish which also surpasses present benchmarks set by the MINI-Z. Your body can be molded with thicker product to higher resist crash damage from procedure in rough landscapes. Integrating comparable ladder- design frame of genuine 4WD cars, the MINI-Z 4x4 boasts a 3-link rigid axle suspension system combining just what would generally speaking be two top links into a person top A-arm to supply maximum suspension movement. A specially created high-torque steering servo permits this device to put its elbows around in hard surface for excellent performance in most challenging rock-crawler conditions. The high-torque 130-size motor brings out the beast in MINI-Z 4x4, particularly tailored for run well inside the low to moderate speed varies typical in crawling. Created to balance exquisite design, scale information and superior driving performance, a lot of the MINI-Z 4x4 requirements is 8 x AAA alkaline batteries (offered separately). Enjoy driving under any conditions, from normal driving to rock crawling while appreciating the wonderful artistic look. The Kyosho Mini-Z 4x4 will be the only mini crawler that delivers a full selection of crawling performance in a substandard package.
● Adopts full-fledged solid axle links just as the 1/10 scale models, ensuring the driving performance and wheel travel required for crawler models.
● Designed with a specially tuned high-torque 130 engine. Moreover, the important thing gear unit features a slipper clutch that protects the drive system by releasing torque when under hefty load.
● Features a high-torque servo specifically made for crawler models, capable of supporting authentic crawling performance. The steering website link optimization achieves the largest steering angle in Mini-Z history.
● Full bearing specification with an overall total of 18 ball bearings. Metal gears, known because of their durability, are utilized in components that bear hefty lots.
● The "KT-531P" transmitter utilizes the FHSS 2.4GHz system and features a sponge in steering wheel to improve operability.
● Comes as a totally come up with, ready-to-run model, needing just the insertion of batteries in the first place operation.
● An optional light set (MZW429R) are set up together with the circuit board. The lights response throttle procedure, as well as the headlight's lighting period could be modified freely—from constant illumination to blinking—via the transmitter's trim.
● Supports the individually offered gyro item (MZW446), and like RWD/AWD show, manual changes are formulated through the amount control.
● Designed with popular BS Goodrich tires.
GR (Gazoo Racing) takes the currently solid off road performance using this world-famous SUV as much as a larger degree with strengthened suspension system system and advanced level electronic settings. Leading bumper and grille are exclusive towards GR Sport model.
the same ladder framework and multi-link rigid-axle suspension popular in popular 1: 10-scale off-road models, is condensed into Mini-Z size the absolute most articulation and gratification obtainable in any mini RC vehicle.
The Mini-Z 4x4 includes a ladder framework design with metal vertical meals, along with different molded components, to deliver the maximum security of of rigidity and flex for superior performance and durability.
Solid front side and back axles function links with metal rods and captured pole ends. Ring and pinion gears, and also other gears and components, component metal construction to withstand the hefty lots underneath the many challenging driving conditions.
Leading axle features perfect Ackermann geometry. Because of the advanced level design of axle housing plus the other steering elements, This model features the tightest switching radius in Mini-Z history. This implies the Mini-Z 4x4 has exemplary administration capability for such a thing including casual driving to hard-core crawling.
Tires and tires that are specific every single model are an important focus for the Mini-Z 4x4.
Steel gears are utilized in areas prone to high lots to ensure durability.
The Mini-Z 4x4 features a specially-designed high-torque motor that is unique in Mini-Z World. It's optimized for optimum torque, therefore develops more power at lower rates.
the utmost effective drive effectiveness is achieved using the included pair of 18 ball bearings, factory installed to ensure the smoothest most useful operation feasible, right right out of the package.
TECHNICAL DATA
- Length 207.0mm
- Width 88.5mm
- Height 90.0mm
- Chassis Type MX-01
- Wheel Base 120mm
- Tread F/R: 72.7mm
- Weight 242.0g (excl. battery)
- Motor/Engine 130 Class
- Gear Ratio 55.44: 1/46.20: 1/39.60: 1/34.65: 1/30.80: 1/27.72: 1
- Front Tire Diameter ?37.0mm
- Rear Tire Diameter ?37.0mm
- Front Tire Width 12.0mm
- Rear Tire Width 12.0mm
- Battery 4 x AAA alkaline
- Transmitter Syncro KT-531P
- Speed Approx. 2.7km/h?5.4km/h
- Running Time Approx. 60 mins
KIT CONTENT
- Complete framework with integrated electronic devices.
- Factory-painted human body detail by detail with many fine details
- KT-531P 2.4GHz transmitter
- Pinion gear set(10T?12T?14T?16T?18T?20T)
- 3 forms of pinion gear spacers
REQUIREMENT TO RUN
- 4 x AAA batteries for the transmitter
- 4 x AAA batteries for framework (Alkaline or NiMH)
