XRAY 330011 NT1 2015 Specs - 1/10 Luxury Nitro TC [XR-330011]

Price:

AUD$862.35

Brand:

XRAY

Model:

XR-330011

Not Available

Please kindly input your name and email address, we will inform you once we have the restocking.

Or you may find similar product under the
R/C Models - On-Road - Touring Cars - Nitro Powered category

Write a review

alt="XRAY 330011 NT1 2015 Specs - 1/10 Luxury Nitro TC" title="XRAY 330011 NT1 2015 Specs - 1/10 Luxury Nitro TC"

Description

Dimensions

Class: 1/10 nitro touring car
Length w/o human body: 381 mm
Chassis size: 341 mm
Wheelbase: 258~260 mm
Width: adjustable 197~200 mm
Weight: 945 g
Ready-to-run fat: 1630 g

Chassis

Chassis: CNC-machined 3.0 mm Swiss 7075 T6 aluminum
Shock towers: machined laminated carbon graphite (front side 2.5mm + straight back 3.0mm) with numerous shock mounting and camber website link roll center positions
Radio tray: machined laminated carbon graphite 2.5mm

Drivetrain

Type: triple gear, 4WD
Final drive ratio (FDR): 2-speed: very first 7.56; 2nd 5.27 (at 1:1 overdrive)
Front differential: sealed, silicone-filled gear diff
Rear differential: sealed, silicone-filled gear diff
Drive axle: front CVD drive shafts - Hudy Spring Steel back dogbone drive shafts - Hudy Spring metal
Suspension: pivot ball suspension
Shocks: machined aluminum, oil-filled, coil-over shocks paid off for improved suspension system system travel
Pinion gear (std): hardcoated aluminum 1st: 16T ; 2nd: 21T
Spur gear (std): molded composite first: 59T ; 2nd: 54T
Arms: standard

Adjustability

Ride height: adjustable front side + rear
Camber: adjustable front part + rear
Caster: adjustable front
Toe: adjustable front part + rear
Downstops: adjustable front side + rear
Roll center: adjustable front part + rear
Ackermann: adjustable front
Front anti-roll pubs: without option - adjustable blade design or wire design 2.6mm
Rear anti-roll bar: cable style 2.0 mm

Gear

Wheels: perhaps not included
guidelines: full-color guide with 3D pictures (48 pages)
Set-up book: 2-color Set-Up Book (39 pages) not included, made for get a hold of just and set-up sheet
Packaging: carton industry with plastic bags with parts
Additionally included: Authentication Certificate, elements list & exploded view, decals
Not included: radio system (transmitter and receiver), individual transponder, steering & throttle servos, motor, manifold & exhaust, beginner industry & starter field battery power, receiver battery power, glowplug igniter, battery pack charger, 1/10-scale bodyshell (200 mm), wheels & tires, Lexan® paint, model R/C automobile fuel (nitromethane), tape, air conditioner filter & oil, CA glue, bearing oil, medium-grade (blue) threadlock, tire truer, tools

Remark :

Due to limited stock availability, please notice that some XRAY items may have to order from the factory and the ready time is around 4-6 weeks. Customer purchases the item is assumed to accept the waiting time which allows us to order directly from the manufacturer if the item is out of our warehouse.
