XRAY 350013 XB8 2018 Specs [XR-350013]

Price:

AUD$1,129.70

Brand:

XRAY

Model:

XR-350013

Not Available

Please kindly input your name and email address, we will inform you once we have the restocking.

Or you may find similar product under the
R/C Models - Off-Road - Buggy - Nitro Powered category

Write a review

alt="XRAY 350013 XB8 2018 Specs" title="XRAY 350013 XB8 2018 Specs"

Description

Dimension

Length: 500 mm
Chassis size: 399.5 mm
Wheelbase: 322~328 mm
Width: 310 mm
Weight: 1868 g
Approximate operating fat: 3205 g

Chassis

Chassis: 3 mm CNC-machined Swiss 7075 T6 hardcoated aluminum
Radio tray: Composite 1-piece
Central diff top deck: Composite
Braces: Composite braces (front side / straight back)

Suspension

Suspension: Pivot ball fully adjustable suspension
Rear suspension system: Lower H-arm with adjustable top camber link
Front suspension: Lower H-arm with adjustable top camber website link A-arm
Rear upright: Composite with dual supply mounting and 2 reduced roll center functions and top aluminum meal with 3 top roll center roles
Shocks: Big-bore shocks with different shock pistons featuring Delrin pistons
Shock towers: Front & rear 4.0mm alu

Drivetrain

Type: Full-time shaft-drive 4WD with center differential
Primary: steel spur gear / clutchbell
Drive shafts: HUDY Spring Steel universal drive shafts in-front & CVD in rear
Central shafts: HUDY Spring metal CVD drive shafts
Differentials: Sealed, 6 gear, silicone-filled
Clutch: Aluminum 3-shoe
Bearings: Rubber-sealed

Gearing

Pinion: 14T front side / rear
Crown gear: 46T front / rear
Clutchbell: 13T
Spur gear: 46T

Body, Tires, Wheels & Misc.

Body: XRAY XB8 High Speed '16 body
Tires: maybe not included
Wheels: perhaps not included, standard 17 mm hub
Fuel tank: 123cc ability with capacity-adjustment portions, with hypertonic tank lid and interior stone-type drifting filter

Adjustment possibilities

Standard modification: Camber, caster, toe-in, wheelbase, kick-up, anti-squat, paid down & top roll facilities, kingpin, Ackermann, bump steer, Multi-Flex, fat balance
Items not included
Engine, Exhaust system, Electronics (broadcast, Receiver, Servos, Batteries), Wheels, Tires, Tools, Wheel tool, Receiver battery, Fuel, change, start industry, Glow heater, Paint, Charger, Universal unit for all nuts and turnbuckles, Set-up guide.

Remark :

Due to limited stock availability, please notice that some XRAY items may have to order from the factory and the ready time is around 4-6 weeks. Customer purchases the item is assumed to accept the waiting time which allows us to order directly from the manufacturer if the item is out of our warehouse.
