XRAY 360006 - Xray XB4'19 - 4WD 1/10 Electric Off-road Car  [XR-360006]

XRAY XB4’19

2018 All-new:

• Recent EOS Champion, European Champion, United States Of America Champion and World Champion platform
• Redesigned framework accommodates brand-new reduced engine mount to diminish the CG
• Lower engine mounts decrease the fat host to engine and primary slipper clutch/diff, increasing cornering rate and stability
• Redesigned lower composite core bulkhead fits the latest paid down aluminum engine mount
• Redesigned component guard allows motor be placed lower
• Improved shock absorber reduced shims give more accurate shock shaft movement
• Improved construction and manufacturing precisely both front side & back differential crown gears results in quieter procedure and increased reliability

General:

• Designed for best performance anyhow degrees of racing
• Engineered with understanding of smallest details
• Manufactured with popular imaginative craftsmanship from premium European materials
• EFRA, ROAR, FEMCA spec compliant for stock and modified racing
• Super a simple task to build, arranged, keep, and drive
• Developed, designed and styled by Dipl. Eng. Juraj Hudy, manufactured exclusively by XRAY in Europe on earth's numerous advanced RC production facility
• Revolutionary off road platform with brand-new standard for premium quality, reliability and performance
• Premium XRAY solution & help

Chassis:

• Smarter framework fat balancing choices help the engine mount and center diff set up to get frontwards or backwards
• Unique XRAY Multi-FlexTM technology for effortless chassis flex adjustment
• Swiss 7075 T6 hardcoated 2.0mm aluminum chassis with countersunk holes for flush, smooth underside
• Tough composite side guards perfectly fit the framework to seal against dust and guard against component impacts
• Compact electronic devices plate enables mounting the rate controller for quick & easy decrease and assembly
• Graphite front side, main & right back top decks separate from chassis flex adjustment and work simply within the front, main, and rear diff assemblies
• Composite & graphite framework braces for fine-tuning of the framework flex
• Independent servo mount allows the steering servo become set up to your framework without touching it, ensuring the removal of unwanted framework tweak and improvement of overall traction
• Two different battery pack straps quick -or- long included. The long battery power strap enables battery power become setup either frontwards or rearwards
• Battery foam right back spacer ensures the battery power wont fall out
• Thick 3.5mm graphite front surprise tower & 3.0mm back surprise tower with multiple surprise mounting and roll center positions
• Extra robust front side part & rear bulkheads enable usage of the differentials only using 4 screws

Differentials & Drivetrain:

• Front & backside gear differentials with adjustable oil viscosity, featuring 35T top metal gears and 14T steel pinion gears
• Molded front & straight back gear differentials for super-smooth, maintenance-free procedure, features long-lifespan HUDY Spring Steel™ outdrives

• Innovative aluminum motor mount enables frontwards or rearwards engine destination for fat stability adjustment
• Motor eccentric mounting dish inserts into a motor holder/drivetrain help, allowing fast & easy motor rotation for gear mesh and safeguarded clamping with one screw

• Robust central slip-adjustable clutch with 81T main spur gear molded from exclusive key mixture of composite material
• Internal 1:2.5 drive ratio
• 3-pad slipper clutch with ultra-efficient SLS material to obtain additional efficient & exact slide modification, and HUDY Spring Steel™ hardened outdrives for extra lifespan and reliability
• Constant velocity drives (CVD) are manufactured from special HUDY Spring steel for paid off fat and increased durability. The shafts are hand ground for maximum precision
• Safety collars for most CVD drive shafts to keep mounting pins securely in place
• Ultra-lightweight 12mm wheel hex drive hubs CNC-machined from Swiss 7075 T6 not forgetting black-coated have actually ultra-true hex clamping design which guarantees solid mounting of wheel
• Optional 14mm offset wheel hex drive hubs readily available for super-fine track-width modification: -0.75mm, 0mm, +0.75mm and 12mm optional wheel hex drive hubs: -0.75mm, +0.75mm, +1.5mm, +2.25mm, +3.00mm, +3.75mm, +4.5mm
• Full set of 22 high-speed, blue-sealed ball-bearings used through the drivetrain to make certain maximum efficiency, degreased and oiled with Aero Shell® Fluid 12 for maximum smoothness and endurance

Suspension:

• Swiss 7075 T6 aluminum suspension system holders front and rear
• Integrated Suspension system Settings (I.S.S.) for fast & easy suspension system geometry developing using eccentric bushings placed into aluminum suspension system holders
• Specially-designed suspension system system elements made out of very carefully developed personalized composite mixtures to make sure appropriate flex and durability
• Race-perfected suspension system geometry for superior performance and flexibility in most race conditions.
• Lightweight 1-piece caster blocks with preset 9° caster with easy adjustable roll center place featuring bigger areas for fast and simple disassembly of CVDs; optional 6° & 12° caster obstructs available
• Front chassis function pre-angled caster of 8° along with the adjustable I.S.S. settings a mixture 16~20° of total caster are achieved
• Tiny yet robust steering blocks molded from a particular composite combination for maximum energy featuring adjustable paid off roll center.
• Very compact 0° toe-in rear uprights work 3 different top roll center jobs, staggered inner/outer bearing sizes for improved load help and unsprung weight, and wheelbase adjustability via included shims
• Oversized outer bearings in uprights to for increased powerful loads
• HUDY Spring SteelTM item for turnbuckles (featuring a tougher core) may be used for front & rear upright linkages, steering system, and servo saver
• Anti-roll pubs made of special springtime metal product to aid the vehicle at both front side and rear are installed toward diff situations & can be simply modified via linkages; laser-engraved markings for effortless recognition, for sale in different sizes for fine-tuning

Steering:

• Simple, effective dual-arm steering system with integral adjustable servo saver guarantees perfect steering and simple Ackermann and bump steer adjustment

Shocks:

• Consistent, dependable membrane-free big-bore shocks with bleed-screw shock cap design function up-stop surprise pole travel modification (via O-rings) and downstop modification (via shims under pistons)
• Swiss 7075 T6 aluminum surprise systems, paid down nut & bleeder surprise caps are hard coated
• Super-precise molded Delrin™ pistons can be acquired with 2-hole design & opening diameters 1.6mm and 1.7mm for precise surprise adjustment; for customized modification, a couple of blank pistons (no holes) are included
• Shock rods are machined from a particular metal product, precision hand-ground for maximum smooth procedure as well as hardened for increased lifetime
• Shock springs are faster enabling more fine trip height modification; manually calculated, chosen and matched into pairs to ensure equal size and damping traits; laser etched for effortless recognition. Two types of springtime sets are included in the kit.
• Full distinct linear -or- progressive surprise springs available
• Premium silicone oils laboratory tested and calibrated to be sure highest possible consistency and quality

Bumper, Body, Wheels:

• Strong composite back wing holder
• Front paid off bumper protrudes from base of this framework to absorb all effects from contact relating to the framework plus the track surface
• Beefy 6mm dense human anatomy articles from unique composite material for optimum strength
• High-downforce XB4 body is superior, low-profile, and aerodynamic to perfectly fit the XB4 design, with front screen and top roof motion systems for appropriate venting, and side downforce areas and top primary rib for higher stability
• Specially produced 12mm hex hub tires for high-competition competition; featuring reinforcement ribs to remove deformation and molded from multipurpose product to retain type despite effects

Assembly, Set-up & Help:

• Premium 3D full-color Guidelines & supplementary sheets
• To grasp the set-up possibilities we suggest the famous HUDY Set-up Book which is laden up with over 40 pages of top-quality images and easy-to-read RC car set-up explanations
• Exclusive Virtual On Line Setup Sheet database with thousands of set-up sheets for competition tracks over the world
• Premium, unmatched XRAY on the web help

Modification Possibilities:

• Fully-adjustable front part and rear suspension system system geometry: caster, camber, toe, kick-up, anti-squat, ride height, downstops, track-width, roll center, wheelbase, roll facilities, Multi-Flex™
• Adjustable front side & backside gear differential action (via oil viscosity)
• Adjustable slipper clutch
• Adjustable HUDY Sprint Steel™ turnbuckles (steering, front & back top links)
• Multiple upper & lower surprise mounting areas at front part & rear
• Adjustable Ackermann and bumpsteer
• Adjustable front part & right back anti-roll bars
• Chassis pre-drilled holes for fat balance adjustment
