XRAY 360007 XB4 20  [XR-360007]

XRAY XB19

2018 All-new:

• Recent EOS Champion, European Champion, United States Champion and World Champion platform
• Redesigned chassis accommodates groundbreaking lower engine mount to diminish the CG
• Lower engine mounts reduce the fat position of motor and primary slipper clutch/diff, increasing cornering price and stability
• Redesigned reduced composite central bulkhead fits the most recent lower aluminum engine mount
• Redesigned component guard allows motor to be positioned lower
• Improved shock absorber reduced shims give more exact shock shaft movement
• Improved construction and production precisely both front & rear differential top gears leads to quieter procedure and increased dependability

General:

• Designed for greatest performance at all degrees of racing
• Engineered with focus on smallest details
• Manufactured with popular artistic craftsmanship from premium European materials
• EFRA, ROAR, FEMCA spec compliant for stock and modified racing
• Super easy to build, setup, keep, and drive
• Developed, developed and styled by Dipl. Eng. Juraj Hudy, produced solely by XRAY in Europe regarding planet's most advanced RC production facility
• Revolutionary off-road platform with groundbreaking standard for premium quality, reliability and performance
• Premium XRAY solution & help

Chassis:

• Smarter chassis fat balancing options allow the engine mount and center diff create to maneuver frontwards or backwards
• Unique XRAY Multi-FlexTM technology for simple framework flex adjustment
• Swiss 7075 T6 hardcoated 2.0mm aluminum framework with countersunk holes for flush, smooth underside
• Tough composite part guards totally fit the framework to seal against dirt and guard against component impacts
• Compact electronic devices plate permits mounting the price controller for fast & easy decrease and assembly
• Graphite front, main & back top decks separate from chassis flex modification and work just contained in the front, main, and straight back diff assemblies
• Composite & graphite framework braces for fine-tuning of framework flex
• Independent servo mount allows the steering servo become installed on framework without touching it, ensuring the reduction of unwelcome framework tweak and improvement of general traction
• Two different battery straps brief -or- very long included. The long battery strap allows battery power become set up either frontwards or rearwards
• Battery foam back spacer guarantees the battery pack will not fall out
• Thick 3.5mm graphite front surprise tower & 3.0mm rear surprise tower with multiple surprise mounting and roll center positions
• Extra robust front & backside bulkheads allow usage of the differentials only making use of 4 screws

Differentials & Drivetrain:

• Front & right back gear differentials with adjustable oil viscosity, featuring 35T top steel gears and 14T metal pinion gears
• Molded front & backside gear differentials for super-smooth, maintenance-free procedure, features long-lifespan HUDY Spring Steel™ outdrives

• Innovative aluminum engine mount enables frontwards or rearwards motor place for fat stability adjustment
• Motor eccentric mounting dish inserts into an engine holder/drivetrain support, allowing fast & easy motor rotation for gear mesh and safeguarded clamping with only one screw

• Robust central slip-adjustable clutch with 81T primary spur gear molded from exclusive key blend of composite material
• Internal 1:2.5 drive ratio
• 3-pad slipper clutch with ultra-efficient SLS material for much more efficient & precise slip adjustment, and HUDY Spring Steel™ hardened outdrives for additional lifespan and reliability
• Constant velocity drives (CVD) are manufactured from special HUDY Spring steel for paid fat and increased durability. The shafts are hand ground for maximum precision
• Safety collars for a number of CVD drive shafts to help keep mounting pins securely in place
• Ultra-lightweight 12mm wheel hex drive hubs CNC-machined from Swiss 7075 T6 as well as black-coated have ultra-true hex clamping design which guarantees solid mounting associated with the wheel
• Optional 14mm offset wheel hex drive hubs readily available for super-fine track-width adjustment: -0.75mm, 0mm, +0.75mm and 12mm optional wheel hex drive hubs: -0.75mm, +0.75mm, +1.5mm, +2.25mm, +3.00mm, +3.75mm, +4.5mm
• Full pair of 22 high-speed, blue-sealed ball-bearings utilized through the drivetrain to ensure maximum efficiency, degreased and oiled with Aero Shell® Fluid 12 for optimum smoothness and long life

Suspension:

• Swiss 7075 T6 aluminum suspension system holders front and rear
• Integrated Suspension system Settings (I.S.S.) for fast & simple suspension system geometry establishing utilizing eccentric bushings inserted into aluminum suspension system holders
• Specially-designed suspension system elements manufactured from carefully developed tailor-made composite mixtures to be sure appropriate flex and durability
• Race-perfected suspension geometry for superior performance and freedom in most race conditions.
• Lightweight 1-piece caster obstructs with preset 9° caster with effortless adjustable roll center destination featuring larger spaces for fast and simple disassembly of CVDs; optional 6° & 12° caster obstructs available
• Front framework function pre-angled caster of 8° along with the adjustable I.S.S. settings an assortment 16~20° of total caster may be achieved
• Tiny yet robust steering obstructs molded from a certain composite mixture for maximum power featuring adjustable paid down roll center.
• Very compact 0° toe-in right back uprights function 3 various top roll center roles, staggered inner/outer bearing sizes for improved load support and unsprung fat, and wheelbase adjustability via included shims
• Oversized outside bearings in uprights to for increased dynamic loads
• HUDY Spring SteelTM material for turnbuckles (featuring a tougher core) may be used for front part & rear upright linkages, steering system, and servo saver
• Anti-roll bars manufactured from unique springtime metal item to guide the automobile at both front side and back are installed towards diff instances & can be easily modified via linkages; laser-engraved markings for simple recognition, accessible in various sizes for fine-tuning

Steering:

• Simple, effective dual-arm steering system with integrated adjustable servo saver guarantees perfect steering and simple Ackermann and bump steer adjustment

Shocks:

• Consistent, dependable membrane-free big-bore shocks with bleed-screw shock limit design function up-stop surprise pole travel adjustment (via O-rings) and downstop modification (via shims under pistons)
• Swiss 7075 T6 aluminum surprise bodies, lower nut & bleeder surprise caps are hard coated
• Super-precise molded Delrin™ pistons are available with 2-hole design & opening diameters 1.6mm and 1.7mm for accurate shock modification; for customized modification, some blank pistons (no holes) will also be included
• Shock rods are machined from a particular metal item, precision hand-ground for maximum smooth procedure as well as hardened for increased lifetime
• Shock springs are smaller enabling more fine trip height modification; by hand determined, chosen and matched into pairs to ensure equal size and damping faculties; laser etched for easy identification. Two types of spring sets are included in the kit.
• Full form of linear -or- modern shock springs available
• Premium silicone oils laboratory tested and calibrated to be sure maximum consistency and quality

Bumper, Body, Wheels:

• Strong composite straight back wing holder
• Front reduced bumper protrudes from base related to framework to take in all effects from contact in the middle of your framework plus the track surface
• Beefy 6mm thick human body posts from unique composite item for optimum strength
• High-downforce XB4 human anatomy is superior, low-profile, and aerodynamic to completely fit the XB4 layout, with front screen and top roof movement stations for appropriate venting, and part downforce areas and top main rib for higher stability
• Specially produced 12mm hex hub tires for high-competition race; featuring reinforcement ribs to get rid of deformation and molded from actually versatile product to retain shape even after impacts

Assembly, Set-up & Help:

• Premium 3D full-color Instruction Manual & supplementary sheets
• To grasp the set-up opportunities we suggest the famous HUDY Set-up Book that will be laden with over 40 pages of top-quality images and easy-to-read RC vehicle set-up explanations
• Exclusive Virtual Online Setup Sheet database with thousands of set-up sheets for race songs across the world
• Premium, unmatched XRAY on line help

Modification Possibilities:

• Fully-adjustable front side and back suspension system geometry: caster, camber, toe, kick-up, anti-squat, ride height, downstops, track-width, roll center, wheelbase, roll centers, Multi-Flex™
• Adjustable front part & backside gear differential action (via oil viscosity)
• Adjustable slipper clutch
• Adjustable HUDY Sprint Steel™ turnbuckles (steering, front & straight back top links)
• several upper & reduced shock mounting areas at front side & rear
• Adjustable Ackermann and bumpsteer
• Adjustable front & rear anti-roll bars
• Chassis pre-drilled holes for fat stability adjustment
