XRAY 370011 X12 2020 EU Specs  [XR-370011]

XRAY X12

2019 All-new Specs

• All-new EU and Usa Edition both created & optimized for particular traction conditions
• All-new EU Edition is optimized for low-, medium-, and high-traction conditions
• All-new United States Of America Edition is optimized for high- and very-high traction conditions
• All-new 2.5mm graphite framework for EU Edition with battery power backstop grooves
• All-new 2.0mm Swiss 7075 T6 aluminum framework with battery backstop grooves
• All-new rear wheelbase adjustment
• All-new top clamps with composite bushing for better durability
• All-new bulkheads use new top clamps
• All-new graphite backside brace with integral backstop and O-ring battery pack mount system
• All-new O-ring for securing the battery
• All-new adjustable graphite battery backstop with 4 positions
• All-new longer front part graphite bumper owner

General

• XRAY 1/12 pan-car with authentic 100per cent self-developed XRAY parts, produced and manufactured by XRAY in Europe
• Legendary XRAY premium design, workmanship & item quality and unmatched awareness of the best details
• Simple yet effective and proven design, well thought-out details, unmatched precision of small details
• High-competition design with focus on ultra-low fat, causing super-lightweight construction
• Optimized for interior carpet racing also outside asphalt racing

Chassis

• EU Edition featuring CNC-machined framework from stiff custom-manufactured 2.5mm high-grade graphite product with specially-designed substance for carpeting and asphalt racing
• US Edition featuring CNC-machined framework from premium 2.0mm Swiss 7075 T6 aluminum material
• Chassis & back pod feature pre-drilled centerline holes for maximum fat security adjustment utilizing HUDY Balancing Tool #107880
• Chassis includes holes and grooves for composite battery pack backstops
• Body posts with fully-adjustable human anatomy holders; optional super-fine +1 or +2mm human body backstops created for on top of that human body height adjustment
• Chassis design permits either horizontal or straight battery pack placement
• Chassis design permits to regulate vertical battery pack placement
• Chassis design enables to regulate the key wheelbase

Front suspension:

• High-competition, fully-adjustable front suspension system system with super-clean design of most composite suspension parts
• EU Edition featuring front paid down & top fingers and steering obstructs created from difficult material to make the vehicle better to drive and present smoother steering
• US Edition features unique graphite suspension system hands that reduces torsional flex regarding the fingers inside the corners of very-high traction tracks, making the car more reactive and much more straightforward to drive
• Shims included for adjusting upper supply position
• Precision steering block and front upper ball bones to get more exact steering
• Bumpsteer shims for enhanced steering
• Lower suspension system system fingers feature smart eccentric aluminum inserts for fast & easy track-width adjustment
• Optional aluminum 0.5mm and 1.0mm eccentrics for establishing track width
• Ride height adjustment shims for quick, exact, and hassle-free ride height modification for various track conditions. Number of 0.2, 0.4, and 0.6mm ride height adjustment shims are included.
• fast & simple front side caster modification via included clips
• All composite elements manufactured by XRAY using premium self-developed composite mixtures which guarantee perfect flex of this suspension system elements yet difficult enough to withstand hefty crashes
• Reactive caster modification (preset 2.5°, 5.0° or 7.5°) via easy-to-change eccentric bushings
• Ultra-precise wheel axles CNC-machined from premium HUDY Spring Steel™ also hardened and hand ground for accuracy fitment
• High-precision, HUDY Spring Steel™ top pivot balls ensure super-fine motion of front part suspension
• Composite lower pivot balls for smooth front suspension system system movement
• Lightweight front top 3mm adjustable HUDY Spring Steel™ camber turnbuckles can withstand hefty crashes
• Quick & simple wheelbase modification by going the entire front side suspension system system on the chassis 2mm front side or straight back

Steering:

• Unique adjustable servo mount can accommodate various types of 1/12 servos, and permits modification of servo to chassis centerline
• Floating servo will not touch framework, eliminating unwanted tweak
• Super-tiny yet robust steering obstructs with specially-designed axles prevent axle rotating while tightening the wheel locknuts
• Pivoting front suspension system system has super-smooth hardened steel kingpins supported by soft springs. Optional medium, difficult, and extra-hard suspension springs available.
• Tiny yet robust servo saver with effortless Ackermann modification via included shims
• 4-spring servo saver for precise, smooth steering
• Specially-designed narrow composite ball joints
• Adjustable, super-lightweight Swiss 7075 T6 aluminum turnbuckles

Back pod:

• Compact, ultra-lightweight slim rear pod consists of high-strength aluminum bulkheads, graphite brace, and strong high-grade 2.5mm graphite plates
• Unique aluminum bulkheads and upper bulkhead clamp are CNC-machined from premium extra-hard Swiss 7075 T6 aluminum, furthermore black colored coated for very long life & stylish look
• Optional eccentric top clamps enables to modify right back wheelbase
• Light, small pod pivot ball decreases the additional weight of going parts and advances the movement selection of a large part pod plate
• Optimized backside pod link positions
• Rear pod top dish includes mounting opening for optional part surprise (for different damping traits)
• Premium-grade graphite upper deck provides solid attachment for surprise absorber to rear pod
• Premium graphite back url brace holds the medial part pipes along side part springs and human anatomy posts
• Premium graphite back hyperlink brace permits to install graphite adjustable battery backstop and features grooves for the O-ring which secures the battery
• Super-easy engine top access
• Rear pod accommodates all motors
• Ride height shims for ultra-fine rear trip height adjustment
• Rear differential features high-grade accuracy carbide balls (for spur gear), hardened and precision-ground metal D- shims, and premium carbide 3x8mm axial thrustbearing
• Ultra-lightweight graphite right back axle
• Precision-molded spur gear produced from XRAY's exclusive composite item, ensuring real running, super-quiet operation, super lightness and robustness for handling effective motors
• Aluminum back hubs machined from lightweight aircraft aluminum, especially lightened and black-coated for fashionable look
• Lightweight straight back wheel mounting screws for reduced rotating weight
• Aluminum backside left wheel hub with center-balanced clamping mounting system, ensures safe mounting while eliminating vibration and run-out
• Easy rear track-width modification via included shims
• Rear human anatomy articles are set up to your framework via an extensive independently-mounted graphite owner, ensuring body downforce is precisely used in the chassis
• Rear pod fat stability may be just modified via shims between engine and bulkhead
• Straight part springs do have more consistent and smoother compression for better out-of part leaving and repaid traction rolling

Shock:

• XRAY micro surprise with comparable design to its “big brother” counterpart in XRAY’s effective T4 touring car platform
• Centralized surprise absorber position
• 4 frontward, 4 rearward surprise destination choices
• Fully-adjustable shock with hard-anodized aluminum shock human body for superior durability, and additionally black-coated for fashionable look
• Fine-threaded surprise human anatomy for fast & simple surprise springtime preload adjustment
• Tiny, slim surprise membrane offers super-smooth damping traits
• Super-soft silicone surprise O-ring for smooth procedure, and improved sealing
• Ultra-finely completed surprise shaft with precise-molded composite shock piston ensures optimal oil movement and smooth shock absorber action
• Simple yet smart shock construction enables fast & simple shock-length adjustment for downstop
• Shock place modification via shimming of mounting ball studs
• Rear pod part stability handled by side pipelines which give equalized lateral damping both in recommendations while eliminating unwanted rebound
• Rigid centrally-mounted surprise mount prevents tweak, and particularly improves lateral stability
• 1-hole piston for improved damping characteristics
• Shock size adaptor is included to improve shock length

Assembly & assist:

• Highest quality composite parts make sure super-precise fitment, effortless set up, and smooth procedure of parts
• Premium 3D full-color Instruction Manual
• Exclusive Virtual Online Setup Sheet database with thousands of set-up sheets for competition songs round the world
• Premium, unmatched XRAY on line help

Modification opportunities:

• Front camber, caster, and toe
• Front & backside wheelbase
• Front & backside track-width
• Front, center, and rear journey height
• Front springs
• Central surprise absorber size & position
• Downstops
• Pod damping
• Bumpsteer
• Weight balance
• Ackermann
• Front brace stiffness
• Differential setting
• Servo position
• Battery position

Specs:
