Tall Reliability & Durability
Built most abundant in tough and top-notch components and along with
cutting-edge firmware, the EZRUN MAX5 can deliver unmatched power
and gratification even for a lot of hardcore of rushing applications, it is additionally
responsive sufficient to safeguard itself from damage considering overloading because of genuine
punishment, overuse or individual blunder.
Great Flexibility & Versatility
With amazing acceleration abilities and a rock-solid, stable
production, the MAX5 are made for instant full-torque start-ups for
wheelies, high-speed rushing on straightaways and powering
through bumpiest landscapes. Someone might have your decision of
adjusting the ESC parameters dependent on their choice and capability.
Relevant to All Weather Conditions
The waterproof and dust-proof design permits the MAX5 become utilized in every climate
conditions minus the dilemma of damage caused towards ESC from water or dirt.
Tall Voltage integrated BEC
The MAX5 has used the world’s very first HV incorporated BEC with a production present as high as 25Amp and a switchable production voltage of
6V-7.4V. The high voltage BEC was created to manage today’s high
voltage servos on need used by large scale vehicles.
Advanced and Secure
Electronic Switch
The MAX5 features an electric switch with a lifespan of over
50000 on/off rounds, housed in an entirely waterproof,
dust-proof and shock-resistant design.
Regular Firmware Updates
Free of Charge
You can update the MAX5 with the Hobbywing USB
LINK software, a multifunction LCD system field and a laptop.
Hobbywing updates its ESC firmware frequently offering you
upgraded features more regularly when available.
Fix Free
The ESC minus the cooling fan is basically maintenance free. The cooling fan is
built to be shockproof, that may reduce damage brought on by
frequent automobile high jumps and landings on difficult areas.
Number of Applications
MAX5 Applications:
The EZRUN MAX 5 provides the ultimate energy enhance solution for some popular 1/5th scale
automobiles like HPI Baja buggy, Losi 5IVE-T Nitro-to-Electric vehicle, and Desert Buggy XL
Nitro-to-Electric buggy. It’s additionally ideal for many other make of 1/5th scale on-road
automobiles, truggies, SCTs and buggies.
Item Specification
Type
- Scale : 1/5th
- Brushed/Brushless : BL
- Sensored/Sensorless : SL
- Waterproof : WP
Specifications
- Cont./Peak Present : 200A/1300A
- Input Voltage : 3-8S LiPo/9-24 Cells NiMH
- BEC Output : Switch Mode:6V/7.4V,6A
Wires & Connectors
- Input cables : Red-8AWG-200mm*1/Black-8AWG-200mm*1
- Output Wires : Black-10AWG-200mm*3
- Input Connectors : No
- Output Connectors : 6.5mm Famale Gold Connectors (pre-soldered onto the PCB)
Fan
- Size : 45.0x45.0x10.0mm
- Voltage Quantity : 5-7.4V
- Powered by : running on BEC
ESC Programing via
- SET Button on ESC : Supported
- LED Program Box : Supported
- LCD Program Box : Supported
- WiFi Module : Supported
- Program Port : FAN/Program Port
Firmware
- Firmware Upgrade : Supported
Size & Weight
- Size : 93.4x58.1x47.8mm
- Weight : 342g
