here is the S9550 minimal Profile Digital Servo w/Two Ball Bearings for
Airplane and vehicle usage and it is sold with "J" Connector Pre-Installed.
This servo will work fine with either 4.8V or 6V receiver packages.
FEATURES: Digitally enhanced Microprocessor Cut About 1/2 of Response
Time From Transmitter Input To Servo Reaction.
Low Profile allows the servo to suit into wings and lay down
down in car framework on the cheap obstruction.
Coreless Motor
Metal Gears
Dual Ball-Bearings
tall Torque
Case is made of Ebony Plastic
Dust and waterproof (Not Waterproof)
High current/Low opposition servo leads.
Ideal for F3A aileron application and 1/10 scale electric touring car
INCLUDES: One S9550 Digital Low Profile Servo w/small Round Horn
Four Rectangular Grommets
One Three Arm Horn
One Wheel Horn
SPECS: Speed: .14 Sec/60 Deg @ 4.8V or .11 sec/60 deg @ 6V
Torque: 67 oz/in @ 4.8V - 83 oz/in @ 6V
(4.8 kg/cm @ 4.8V - 6.0 kg/cm @ 6V)
body weight: 1.6 oz (45g)
Length: 1.6" (41mm)
Width: 0.8" (20mm)
Height: 1.0" (25mm)
REMARKS: S9550 Digital Servo Precautions,
-It is way better to prevent long leads and Y-harnesses particularly with
standard grade cables. If problems are experienced, consider using
heavy obligation cable including Futaba's heavy weight Series or Hobbico's
Pro Series, minimizing lead lengths, and/or removing Y-harnesses.
Current Drain: Futaba S9550 Servo is particularly created for High-
Torque and High-Speed, consequently high Current Drain Is
Normal At business. For Ultimate Effectiveness When Working With This Servo
Please Review The Next Points.
(1) When working with Systems utilizing the Battery Fail Secure Function it Has
a Higher Cut-Off Voltage Setting that'll Cause Shorter
Operation Time.
(2) Whenever starting the Servo Please Check Pushrod Linkage To Make
Sure There isn't any Binding so that you can Prevent extortionate Power
Consumption and minimize steadily the life span associated with engine and Battery.
This digital servo cannot be found in combination with one of these * have always been *
transmitters since the servo fundamental indication is: 1310us).
CONQUEST have been, FG Series (T4FG, T5FGK,T6FG, T6FGK, T7FGK), brand-new Terra-
top, T3EGX, T3PGE, T2NL, T2LGX, T2FR, T2PK series.
**** Otherwise they will work fine with current AM systems *****
