Exemplary engine Governing Speed
High-performance 32-bit processor with a running regularity of 72MHz
coupled with advanced algorithm optimizes the speed governing.
Alongside the adjustable governor parameters guarantees every
pilot an accurate control experience
High Voltage incorporated BEC
The integral switch mode BEC with a variable voltage (6V/7.4V for the Platinum
25A V4, 5V~8V with the action of 0.1V for the Platinum 40A V4), a continuing up-to-date
of over 3A/7A (3A for the Platinum 25A V4, 7A the Platinum 40A V4) and a top
present of 7A/18A (7A for the Platinum 25A V4, 18A the Platinum 40A V4) can
supply adequate power the servos to work effectively.
DEO Technology
The DEO (Driving effectiveness Optimization, or more called "Active Freewheeling")
technology applied inside ESC has many advantages.
● Quicker a reaction towards throttle change.
● greater driving effectiveness, longer flight time.
● Lower ESC temperature and an even more dependable procedure.
Reverse Brake
With the opposite Brake mode enabled when landing can effortlessly
shorten the sliding distance of fixed-wing aircraft to simulate the
landing of a genuine aircraft (within a brilliant short distance). The standard
Brake Mode, Proportional Brake mode, and Brake Disabled mode are
also available; the stopping system quantity is adjustable in normal braking system mode
whilst in proportional braking system mode, the stopping system force is likely to be automatically
allotted in line with the position of radio throttle stick.
Several Protections
Multiple protection features consist of, ESC thermal,
capacitor thermal (HOBBYWING-patented
technology), ESC overload, throttle sign loss
(or Fail secure), and low voltage cutoff effortlessly
prolongs the answer life associated with the ESC.
Other Features
A split development slot to get in touch the programmer with this specific ESC permits individual to
● Program ESC,
● check flight information contain minimal voltage, maximum heat, standardized RPM
and rate curve (in Heli Governing store mode) about the trip information recorded by the ESC,
● Upgrade ESC firmware With a multifunction LCD program industry or a Wi-Fi Module & our
Apple/Android phone App.
Product Specification
Type
- Brushed/Brushless : BL
- High Voltage/Regular : Regular
Specifications
- Cont./Peak Present : 25A/40A
- Input : 3-6S Lipo
- BEC production : Switch Mode:6V/7.4V,3A
Wires & Connectors
- Input Wires : Red-16AWG-100mm*1/Black-16AWG-100mm*1
- Output cables : Black-18AWG-100mm*3
- Input Connectors : No
- Output Connecotors : 3.5mmGold Connectors (Female)
ESC Programing via
- Transmitter : maybe not Supported
- LED Program Card : perhaps not Supported
- LED Program Box : perhaps not Supported
- LCD Program Box : Supported
- WiFi Module : Supported
- Program Port : Separate Program Port
Firmware
- Firmware Upgrade : Supported
Size & Weight
- Size : 47x22x10mm
- Weight : 27g
