Exceptional engine Governing Speed
High-performance 32-bit processor with a running frequency of 72MHz
coupled with high level algorithm optimizes the speed governing.
Together with the adjustable governor parameters guarantees every
pilot a precise control experience
Tall Voltage integrated BEC
The integral switch mode BEC with a variable voltage (6V/7.4V for the Platinum
25A V4, 5V~8V with all the step of 0.1V for the Platinum 40A V4), a consistent present
of over 3A/7A (3A the Platinum 25A V4, 7A the Platinum 40A V4) and a top
present of 7A/18A (7A the Platinum 25A V4, 18A the Platinum 40A V4) can
provide sufficient power the servos to work effectively.
DEO Technology
The DEO (Driving effectiveness Optimization, approximately called "Active Freewheeling")
technology implemented into the ESC has numerous benefits.
● Quicker reaction to the throttle modification.
● greater driving effectiveness, longer flight time.
● Lower ESC heat and a much more dependable procedure.
Reverse Brake
With the Reverse Brake mode enabled whenever landing can effortlessly
reduce the sliding distance related to fixed-wing aircraft to simulate the
landing of a real aircraft (within a super brief distance). The conventional
Brake Mode, Proportional Brake mode, and Brake Disabled mode are
also available; the stopping system quantity is adjustable in normal braking system mode
during proportional braking system mode, the stopping system force are automatically
allotted in line with the place of radio throttle stick.
A few Protections
Multiple safety features consist of, ESC thermal,
capacitor thermal (HOBBYWING-patented
technology), ESC overload, throttle indication loss
(or Fail secure), and low voltage cutoff effectively
prolongs the answer life for the ESC.
Other Features
A separate development port to obtain in contact the programmer on this ESC enables user to
● Program ESC,
● check journey information consist of minimum voltage, maximum temperature, standardized RPM
and rate curve (in Heli Governing store mode) related to journey information recorded by the ESC,
● Upgrade ESC firmware With a multifunction LCD program package or a Wi-Fi Module & our
Apple/Android phone App.
Product Specification
Type
- Brushed/Brushless : BL
- High Voltage/Regular : Regular
Specifications
- Cont./Peak Present : 25A/40A
- Input : 3-6S Lipo
- BEC production : change Mode:6V/7.4V,3A
Wires & Connectors
- Input Wires : Red-16AWG-100mm*1/Black-16AWG-100mm*1
- Output cables : Black-18AWG-100mm*3
- Input Connectors : No
- Output Connecotors : 3.5mmGold Connectors (Female)
ESC Programing via
- Transmitter : perhaps not Supported
- LED Program Card : Not Supported
- LED Program Box : Not Supported
- LCD Program Box : Supported
- WiFi Module : Supported
- Program Port : Separate Program Port
Firmware
- Firmware Upgrade : Supported
Size & Weight
- Size : 47x22x10mm
- Weight : 27g
