Competition Design
The light-weight linked to the expert 120A is made to meet up the users’ needs of a light
fat product for many marine competition which fat is a problem of rate and
endurance. The core system for top-level competition services and products guarantees an individual
first-class control and “abundant” programmable parameter services and products for different
competition environments. (* The ESC is quite relevant to ECO/MONO1)
Splash-proof
The whole circuit board and all the sun and rain onto it went through nano-coating
therapy; this may result in the Seaking professional 120A ESC splash-proof.
Tall Voltage integrated BEC
The integral switch mode BEC with a maximum output of 8A and adjustable
voltage of 6V/7.4V result in the ESC suitable for different high voltage servos.
Tall Durability & Reliability
Reliable equipment (i.e. MOSFETs with extremely low internal opposition) coupled with advanced level
software applications (features low-voltage cutoff protection, thermal protection, throttle sign loss security, and
an such like) guarantees the durability and dependability of the ESC and relevant devices.
Innovative Turbo Function
The world’s initial marine ESC to have implemented the turbo timing function
that will supply the individual the side in the competition with instant turbo boost.
Programming/Upgrading Wirelessly
With Hobbywing’s WiFi module and iPhone or an Android os phone (utilizing the
HOBBYWING WiFi Link computer software setup), an individual can from another location plan
parameters or upgrade firmware without making the control stand.
Efficient Cooling System
The Hobbywing patented heat-conductive copper club address in power board
about the ESC along with water cooling module efficiently and effectively
transfers heat toward exterior thus maintaining your ESC as cool as you're able.
Regular Firmware Updates without Charge
You can upgrade the ESC utilizing the Hobbywing WiFi/USB LINK computer software, a WiFi
module/LCD program package and a smartphone /laptop. Hobbywing updates its ESC
firmware usually providing you with upgraded features more frequently whenever available.
Item Specification
Type
- Brushed/Brushless : BL
- Waterproof : Waterproof (IP55)
Specifications
- Cont./Peak Present : 120A/760A
- InputVoltage : 2-6S Lipo/6-18 Cell NiMH
- BEC manufacturing : modification Mode: 6V/7.4V,4A
Wires & Connectors
- Input Wires : Red-12AWG-200mm*1/Black-12AWG-200mm*1
- Output cables : Black-12AWG-150mm*3
- Input Connectors : No
- Output Connectors : 4.0mm silver Connectors (Female)
ESC Programing via
- Transmitter : Supported
- LED Program Box : maybe not Supported
- LCD Program Box : Supported
- WiFi Module : Supported
- Program Port : individual Program Wire
Firmware
- Firmware Upgrade : Supported
Size & Weight
- Size : 96.6x37.9x10.3mm
- I.D./O.D. of this Water Cooling Pipe : Ф2.0/5.5 mm
- Weight : 87.5g
Applications
- ECO, Mono1/Other Competition ships (≤100cm)
