Serpent SER600039-G Serpent Cobra E-Truggy RTR Green [SER600039-G]

Price:

AUD$740.97

Brand:

Serpent

Model:

SER600039-G

Not Available

Please kindly input your name and email address, we will inform you once we have the restocking.

Or you may find similar product under the
R/C Models - Off-Road - Truggy - Electric Powered category

Write a review

Description

Introduction

The Serpent Cobra E-Truggy in RTR trim is a perfect basher type car that can simply take plenty of beating and its particular also a good package to begin genuine race ! On the basis of the Cobra E-Truggy it is the outright speed, great handling, dependability, rigidness and durability you need.

The RTR package is actually dialed:
-factory assembled rushing chassis
-prepainted and precut low sort truggy human anatomy and big composite backside wing
-premounted truggy tyres/wheels/inserts
-pre-set 4S to 6S capable waterproof 150A speedo ( DragonRC)
-2000kv brushless longbody engine (DragonRC)
-Digital 2.4ghz transmitter (DragonRC)
-Metal gear servo 16kg ( DragonRC-Savox)
-3 oilfilled geardifferentials
-Big bore shocks with rubber dustboots and machined aluminium shocktowers
-Spring metal transmission components and turnbuckles, front part and back cvd driveshafts
-Front and back anti-roll bars
-Large battery-cases with effortless felcron straps
-Machined aluminium chassisplate
-Fully ballraced
-Batteries the automobile and transmitter aren't included

The bodyshell will come in orange, red, green, blue and red, plus a certain kind.

Serpent offers a multitude of optional components because of this car to improve performance, lighter and sometimes even for even nicer appearance.

Main features

Car
Fully expert pre put together and pre-set framework and electronic devices.

Transmitter
DragonRc 2.4 GHz steeringwheel kind transmitter with lots settings and good range. Includes tiny and light receiver.

Speedo
DragonRC waterproof speedcontroller with an enormous 150A capability to manage the brushless engine and 4S or 6S battery pack power

Motor
DragonRC longbody 2000kV brushless motor with simple colorcoded connectors

Body
Prepainted and pre-cut low e-Truggy human body, in 4 main colors orange, red, Green and Blue. ( additionally clear one available as optional)

Tyres
Premounted battle ready tyres / wheels with soft substances and pintype profile for amazing grip.

Chassis
Very narrow 3mm 7075T6 aluminium framework, with machining on top face which makes it lighter in strategic areas and to get a handle on flex. Kick-up front side for appropriate landings. Angled part to boost cornering approval, and protected and easy mounting side guards with 5 screws. Countersunk holes, pouches to position the suspension system brackets. Overall the Truggy is made to keep the extra weight exceedingly main and close to the centerline as possible, generate an excellent basic stability.

Side guards / battery trays
Durable shaped composite part guards / battery power trays that follow the distinct the framework, and mount with 5 screws each part. Front and sides high enough to help keep the dirt out. The guards/trays create many security. The batteries are installed in longtudinal fashion, keeping the extra fat really low in car. The battery pack trays features easy to use Serpent noticeable felcron TM straps to secure the batteries setup. Fits 2S and 3S batteries.

Motormount:
The motor is put within the many optimal place inside automobile, keeping motor-forces and transmission parts / placement in your thoughts. Only one-screw is required to secure the BL motor, to the nicely designed durable machined aluminium motormount. Area for extra motor-cooling available as required. The area for the engine allows mounting all popular buggy and (monster)truggy motors.

Composite framework braces
Allows the framework to flex which assists improve bump maneuvering. Front and rear.

Front bumper
Nicely curved front side bumper, identical to on the Cobra buggy, to guard leading anti-roll club, suspension brackets, and moves inline with kick-up chassis front for safe landings.

front side suspension
Very long and durable composite reduced wishbones, coupled with top spring-steel trackrods. 2 reduced shock-mount jobs. Downstops may be used as needed. Pivotball type anti-roll club rods.
.
Front steering / servo saver / angled
Innovative angled front side steering construction to cut back the angle of distinction between the full total caster and steering airplane. For that reason you will have less bump steer and a truer steering Ackerman through the complete array of suspension.

Adjustable springtime packed servo-saver system with interchangeable Ackermann dishes. Utilizing the design for the steering bell cranks whenever changing the Ackerman you will not need certainly to adjust your steering tie rods. You merely will simply must adjust your end points in your radio.. super easy to gain access to and set-up.

The Inboard Bell crank keeps the lever and linkage into the vehicle. It'll help out with preventing damage to the steering system. Zero scrub radiuses on steering knuckle, assists in easing the jacking impact created by your steering knuckle offset. It offers a far more direct dropped while maintaining the vehicles chassis more degree while turning.

The front roll center is changed quickly by moving the steering knuckle shims for their appropriate locations.

Topped of with a great composite top-plate.

Front steering-block / c-hubs
Very durable front side steeringblock / C-hub setup .

Drive-shafts
very long and lightweight springtime steel devices with pressed in metal pins, laser-engraved. Same size front and rear.

Wheel-axles / wheel-nut
Serpent springtime steel threaded wheel-axles with lightweight grey anodised aluminium wheel-nuts to help keep the massive truggy wheels/tyres on course.

Captured universal joints
Guarantees you will finish a race without loosing a pin or set screw. All elements, axles and drive train elements have actually really capture pins

Front shocktower
Light, strong and durable machined 5mm aluminium units with 5 jobs for shockangle.

Shock-set front side and rear
16mm big bore shocks, with hard anodized accuracy threaded shock-bodies. Shockboots in silicone synthetic to keep the dirt away . Chromed shock-shafts for supersmooth shockaction . The bigger o bands offer less general force and a greater seal without dragging regarding the surprise shaft.

Suspension brackets
The hinge-pins / hingepin balls are captured in durable composite suspension system brackets . These capture the nylon roll-center inserts.

Anti-roll club / anti-roll club linkage with pivotball
The anti-roll pubs front and right back are constructed with high quality unique springtime steel, and so are captured on diff-cased in ballbearing for perfect guidance and control.

Receiver package / servo mount / speedo mount
Composite one piece radiobox to securely install servoï¿½ s, speedo and receiver. For optimum security the light receiver fits the top-case easy, with a tiny opening permitting cable to protrude. The speedo seats low on a plate right above the framework, therefore brief cables enables you to the motor. The servo is installed in a vertical fashion.

Central diff
Optimised primary gear-diff with 50T super-hard spur-gear . Really small, compact design to lessen rotating mass toward max.

Transmission shafts
Durable but light and slim Serpent springtime steel, laser etched shafts.

Front and back diff
Optimised gear-diff with superhard spur-gears . Small, compact design to reduce rotating mass towards maximum. Identical variation front part and rear. Diff coupler in spring steel seated in big barings for durability.

Rear shocktower
Light, strong and durable machined 5mm aluminum product with 5 roles for shockangle.

Rear uprights
Durable composite rear uprights with 3 camber positions

Suspension brackets rear
Durable composite units with eccentric inserts to alter set-up.

Rear wing mount
The composite back wing mount, allows to enhance the angle of straight back wing.

Rear wing
Two phase high down force wing, has two levels of angle, that also includes 2 fins. Helps improve down force and right line capability

Bodymounts
Nylon bodymounts with wider sitting the human anatomy, securely fastened towards the shocktowers.

Super Minimal profile e-Truck Body
Improves appearance along with keeps the profile minimum. Comes precut and prepainted.

Decals
Applied towards human body.

Oils / grease
Car is come up with with a top quality silicone oils the diffs and shocks and black oil. Threadlock used in which needed.

Manual
Full color manual showing the automobile, specs, recommendations and exploded views. The transmitter and speedo have in fact small split manuals included.

Box
Full color protective field to re-use for car transport or tyres.
