Serpent SER903019 Serpent VIPER 989 40th anniversary 1/8 GP [SER903019]

Price:

AUD$1,176.50

Brand:

Serpent

Model:

SER903019

Not Available

Please kindly input your name and email address, we will inform you once we have the restocking.

Or you may find similar product under the
R/C Models - On-Road - Touring Cars - Nitro Powered category

Write a review

alt="Serpent SER903019 Serpent VIPER 989 40th anniversary 1/8 GP" title="Serpent SER903019 Serpent VIPER 989 40th anniversary 1/8 GP"

Description

The cable type front part anti-roll club is ball raced. You'll be able to change and adjust because of the open front end design. The conventional wire is 2.5mm and 2 optional thicknesses can be found. The pivot ball link system directs the suspension system movement towards the club and enables easy tweak modification.
The steering obstructs are attached to the hands with springtime metal 8.5mm pivot balls, which run really smooth and well protected in nylon cups, and generally speaking are an easy task to modify with a 2.5 hex device.
The ultra-narrow keeps the improved flex characteristics. The framework is milled lower in less load-stressed areas rendering it because light possible but nevertheless stay rigid in areas in which needed.
Of system we kept the initial approach to include loads, effortlessly adjustable inside’s plus the means it is it mounted to lessen vibrations with the use of a carbon fat connection that will be set up in anti-vibration rubbers.
On top of the we've added the opportunity to add a sliding fat right inside front part, set up on a carbon connection. It assisted a tremendous amount while we are avoiding traction roll and fine-tuning the management the 989
The new midshaft construction features a new block. This is certainly designed to move the shaft slightly ahead. The leading gear therefore has become 210mm very long rather than 213mm
This have been done to make use of the sidebelt with only 1 gear tensioner in place of the 2.
due to this the transmission will likely be more free.
The trunk hands function carbon inserts as utilized by the team within Worlds
The front hands in 989 40th anniversary kits will be the open style arms concerning the 977, obviously using the extra mounts the heave brackets
At the globes the group in addition preferred another bumper. It's less steering compared to the 989 bumper but supplied a far more consistent feeling.
If more steering at higher rate becomes necessary, it is always maybe to work with the 989 bumper
Another purpose of this kit will be the “option 2” steeringlevers. These provide a new ackerman for a smother, more linear feeling about the steering
Complete brand new front part springs with another price and progressiveness can also be component of this kit
2.5mm thick radioplate, since used by the group. A bit less steering but more consistent under high hold circumstances
Another treatment for adjust flex that was effortlessly utilized by the team is a brand new additional bracket together with the servosaver
7075 T6 Aluminium 5mm framework dish
The 5mm aluminium framework has perfect symmetrical kind for even flex and fat distribution. The ultra-narrow framework is very light, whilst it nonetheless remains strong in critical places. The Viper 989 company logo is laser etched.
Rather than the 977 bumper, the 989 bumper can be utilized clearly. It offers more steering at high-speed nevertheless it comes with a bit more “nervousness”
The steering obstructs, that are equal left and right, offer one thing to improve the axle place to a “trailing” or “leading” spot, along with capability to change the kingpin-inclination and offset. This enables numerous choices to fine tune steering security generally in most phases the corner. The steering block features an aluminium meal to get in touch the springtime steel track-rods. They will have 2 Ackermann options along with a option 2 lever.
Optional carbon fibre disks are set up regarding the medial part connected with steering obstructs and uprights for aerodynamic modifications.
The long durable front side lower wishbones will be the open-style hands much like the 977. An aluminium shock mount plate is screwed on paid off wishbone. This enables the shock accessory point out be placed further outwards increasing surprise motion. Leading reduced hands are installed on front brackets with nylon holders. The kit includes 2 versions: inside and out. This technique also allows easy and quick front drive shaft upkeep.
obviously the 988 closed arms are usable as well
The left and right interchangeable top hands are mounted with 3 place nylon suspension system pin inserts. The 3 spot inserts enable camber-change modifications and they are held in place by the anodized aluminium top brackets. Below the top brackets, spacers lets you change their angle or height. Caster is adjusted with clips in the upper pivot pins. Comparable clips may applied to the reduced pivot pins to improve wheelbase.
The black colored anodized aluminium front side axle has Japan made one-way bearings. Spring steel drive cups relate genuinely to the long and thin spring-steel drive shafts with CVD system. The ball raced spring steel wheel axles have actually in fact aluminium quick-change levers. The available front end design allows quickly and easy eradication of this leading axle and driveline components.
The central mounted seervosaver enables simple and fast Ackermann modification. The servosaver features a higher mounted insert which might be within 3 jobs. Another 2 Ackermann roles is available concerning the steering blocks.
The tail construction with aluminium brackets is a really available design, that allows for effortless of upkeep and cleansing. Dis-assembly requires the removal of just a few screws. Replacing a belt if needed, is a facile task. The eccentric bearing holders into the rear shaft allow modification of belt stress. The whole rear end is eliminated as you unit through the framework by reduction of just some screws.
The cable sort straight back anti-roll bar is ball raced. It is installed in straight back bearing obstructs and is quite simple to improve and adjust. The traditional wire is 2.5mm and 2 optional thicknesses can be had. The pivot ball link system directs the suspension system movement on club and enables simple tweak adjustment.
The slim solid back axle in Serpent springtime metal has a lightweight 9mm wide 48T pulley. The axle has a double slot the driveshaft pin for lightness and durability. Spring steel, CVD type, drive shafts link the trunk shaft to spring steel wheel-axles with aluminium quick-change levers. A tremendously durable and long lasting drivetrain.
The brand new rear paid down wishbones have a hollow style design with shut bottoms for aerodynamics and split top mounted moulded meals. The lower straight back hands contain the website link the backside anti-roll bar additionally the aluminum mounting plate of a large part shocks. This dish moves the shock mounting position towards outside for improved geometry. Nylon videos are used regarding paid down right back pins to enhance wheelbase.
The durable composite uprights support the ball raced wheel axles, with aluminium quick-change levers. On the up-right spacers is added in pivot ball to boost roll centre and camber modification.
Optional carbon fibre disks are connected to the part of uprights for aerodynamic reasons. A corner uprights are for this hands with springtime steel 8.5mm pivot balls, which run very smooth and well protected in nylon cups, and generally are really easy to adjust with a 2.5 hex unit.
The adjustable backside top camber links mount to a 4 destination rear carbon fibre camber plate.
The rear floating human body mount that is installed on the up-rights with 2 arms is centred by a carbon-fibre and metal guider. The mount has 4 roles on each part to choose from, according to body shell utilized and traction available. The threaded holes on end of this body mount provide you with the choice to include further body-supports
- 4wd belt-driven battle automobile
- Serpent springtime steel axles with fast modification system the tires
- Front and rear springtime steel cvd shafts
- NSK bearings the transmission
- minimal friction belts and ball raced belt-tensioner
- Ebony anodized front shaft with one-way bearings and slim back solid axle
- super low inertia 2-speed gearbox
- separate suspension with hydraulic low-friction shock absorbers
- Ball raced forward and back anti-roll bars
Optionals
a sizable assortment of optional components can be had to further improve performance, rate, weight and appears.
www.serpent/com/903019
Communications
- site
- Promopage
- Facebook website
- Viper 988 Twitter individual team
- Serpent Advanced person Manuals pages
- YouTube video’s
- Online set-up sheets
- Support from distributors, dealers and team motorists all over the world
Merchandising
an ideal choice of shirts, sweaters, coats, caps, bags, tools and decals.
Design
Serpent Viper 989
produced by Michael Salven.
With great help from all team-drivers and 988/977 motorists!
The kit come with a couple of extra's:
1 pc Serpent Pit Mat 40th anniversary
www.serpent.com/1904
Serpent Rugsack 1/8 www.serpent.com/1906
