Serpent SER904005 Serpent Viper 989E 4wd 1/8 EP [SER904005]

Price:

AUD$807.96

Brand:

Serpent

Model:

SER904005

Condition:

Brand New

Quantity:

Write a review

alt="Serpent SER904005 Serpent Viper 989E 4wd 1/8 EP" title="Serpent SER904005 Serpent Viper 989E 4wd 1/8 EP"

Description

Energy delivery starts utilising the batteries. We made area for severe energy, 4S, 6S or more. There's an abundance of area for them, nevertheless they are suprisingly low inside car.
The batteries are installed on a 2.5mm thick carbon plate. They might be mounted in 3 different jobs, changing the CG to change the vehicles behaviour
The elevated speedo mounting meal offers stiffness the battery pack dishes and produces also space for oversized speedos. Also 1-5 scale speedos fit, a tremendously popular choice into the dragster rushing scene
The topdeck is producing enough stiffness for the whole framework and holds the receiver, steering-servo and belt tensioner
We additionally took care with this engine. We created the room for countless engine sizes.
Even long custom made engines have enough room
To avoid unwanted torsional flex, we created a “power box” throughout the motor, causeing the part of the framework exceptionally rigid. To make this happen, the motor mounting meal is attached to the bearing-block for the spur gear shaft, towards the chassis and to the mounting bracket regarding the topdeck
Power will be transmitted further with unbreakable, module 1 steel gears
Further down we changed to an excellent wide, 10mm rear belt. The ability then undergoes the solid straight back axle which carries a n aluminium pulley as well
For the dragster enthusiasts we also provide a wheelie club as an option.
Overview associated with main specs
Chassis
Symmetrical chassis dish optimised flex and
torsion, in 7075 T6 aluminium, anodised and
laser etched. Chamfered sides for lots more
ground approval whenever cornering and
countersunk holes.
Low big bore shocks
Coated threaded shock systems in quality
aluminium. Supersmooth x-ring / machined
bushing package, to guide and seal the springtime-
metal piston rods. Precision machined pistons
a part of 3 kinds. Threaded pre-load
shocknuts in aluminum with O-ring inside. Light but
strong nylon spring-cups. Selected, matched
and paired shock absorber springs with color
coding.
Shocktower front part & straight back
The 3mm carbon fibre front side and straight back shocktower
with 2 jobs leading and 3 functions
the trunk for top surprise mounting.
Steering obstructs
Very strong composite steering obstructs with 2
Ackermann positions, L and R make use of the same .
The steering obstructs feature inserts, which
allow to enhance the kingpin inclination to a
leading or trailing place. The steering
blocks additionally enable usage of the optional carbon
fiber aero disks become set up regarding inexpensive flex
and an even more direct steering feel.
Uprights
Durable moderate type composite uprights, which
seat the wheel-axles bearings. The upright
supplies the mounting place the metal
camber-rod with L/R threading. Roll centre
changes might be made over the upright with
shims. The upright is installed along with the
optional carbon fiber aero disks for much more rear
hold and right line security.
Wheel axles and driveshaft
The durable spring steel wheel axles combined
with springtime metal driveshafts bring the power
towards the tires.
Pullies
Precision moulded super-true pullies, which
function holed sidewalls allowing debris move out
easier. Light and durabele.
Belts
Minimal friction Kevlar reinforced belts with fine
pitch. Longlasting and smooth.
Decals
The 989 includes one sheet with Serpent
generic logos and something with 989 logos. Decals
are extremely slim material and come pre-cut.
Serpent Viper 989E
Created By Michael Salven.
