Tamiya 58489 - 1/10 RC High Performance 4WD Off Road Racer Avante 2011  [58489]

In March 1988, Tamiya released an electrical R/C 4WD rushing buggy called the "Avante" and has now since become a unique machine in Tamiya's R/C history. The device showcased a distinctive shaft-driven 4WD system that was taken from Tamiya's very first 4WD R/C buggy, the Hotshot. It featured a highly advanced design including a FRP double-deck framework layout, longitudinal engine & battery pack roles, and a formula-type body with chassis fairing. It was prepared with innovative components such as for example a tight gearbox with 3 tiny planetary gears, a center diff to improve stability, a completely adjustable suspension, and cam-lock wheel caps.

The Avante was a unique R/C device which showcased a cutting-edge design. After two decades, a few of the Avante's mechanisms are becoming standard features on modern R/C cars. The greatest pure race buggy returns in 2011.

Tamiya has given the Avante (2011) the unique re-release therapy the same as other re-released buggies for instance the Buggy Champ and Hotshot. Here is a quick introduction associated with the improved points.

• Main frame material happens to be changed from FRP to carbon fiber. Original FRP upper/lower decks have already been replaced with 2.0mm dense carbon fiber decks to help increase framework strength and rigidity. Chassis layout is optimized for setting up modern R/C gear.
• Carbon Fiber Rear Damper Stay back damper stay is thicker versus original and its particular material has additionally been changed to carbon fiber. Kept and right stays are linked to further enhance rigidity.
• Assembly Universal Shafts WO universal shafts are utilized for both front and backside to lessen friction loss.
• Better Damper Maintenance The gold-colored oil damper cylinders feature base caps for easier upkeep such as changing o-rings.
• Durable Polycarbonate Body Shell your body, wing, and framework fairing have been created using polycarbonate for superb off road durability.
• Wheel Axle/Clamp Type Wheel Hubs Wheel axles happen changed to standard pin-secured kind. Together with aluminum wheel hubs, secure wheel accessory can be done. The hex wheel hubs help accessory of off road tires such as Item 53880 big Dish tires (4WD/Front, 62/25) and Item 53881 Large Dish Tires (back, 62/35) as well as the original cam-lock kind wheels.
• Duralumin front knuckles the first die-cast front knuckles are changed with duralumin knuckles to help enhance strength and durability. Brand new knuckles feature equivalent shape while the original.Compatible with an extensive selection of battery pack packs. The Avante (2011) works with a wide range of Tamiya battery items such as for instance Ni-Cd, high-capacity Ni-MH, and lightweight LF battery pack packages.
• Latest R/C techniques The Avante works along with Tamiya R/C systems including the 2.4GHz systems.
• The first Packaging can be Revived! The package with this re-release model is sold with the exact same design and measurements while the initial Avante. In addition, just as the original Avante, all the parts are stored in blister packages.
• The "Avante" logo and rear wing sticker will continue to be just like the initial. Other stickers is likely to be of a brand new Tamiya design.

Specs:



• Length: 420mm
• Width: 240mm
• Height: 115mm
• Wheelbase: 260mm
• Tread (L/R): 200mm
• Minimum Ground Clearance: 40mm
• Weight: 1300g
• Double-Deck Frame
• Tires (F/R): 38/88mm
• Polycarbonate Body
• F/R Multi-Link Suspension
• F/R Metal Oil Dampers
• Gear Ratio: 1:8.33

Features:



• Mini resin bumper.
• Front double wishbone suspension system.
• Radius supply protector.
• Front stabilizer.
• Front strut towerbar for improved rigitity.
• Front C.V.A. oil damper with tapered coils springtime.
• Pin increase tire.
• Internal sponge.
• Cam-loc wheel.
• Steering tie rod.
• Universal joint.
• Front gearbox features compact planetary differential w/ steel pinion gear.
• Carbon top deck, area of the double-deck chassis layout.
• Metal propeller shaft.
• Steering servo (maybe not included).
• Polycarbonate undertray.
• Longitudaly-mounted motor.
• Receiver (maybe not included).
• ESC (included).
• Back gearbox upper access hatch.
• Back metal C.V.A. damper unit.
• Rear strut tower.
• Back double wishbone suspension system.
• Back stabilizer.
• Adjustable wing mount.
• Polycarbonate human anatomy.
