Specs:
•Based on IFMAR/ROAR/EFRA/BRCA design requirements.
•Modified winds, 13.5T, 17.5T, 21.5T engines are typical ROAR authorized ( BRCA pending).
•Motor proportions (Diameter x size) 35.8mm x 52.2mm.
•Shaft Diameter: 3.17mm
•Magnet Measurements
12.3 x 5x 24.2mm(3.5T~9.5T),
12.5 x7.2x25.2mm (10.5T~21.5T),
12.3 x7.2x25.2mm (25.5T)
Variable timing end bell
•Weight: ~150g (varies between turns)
•Recommended RC Model vehicle: 1:10 touring, Buggy, MINI vehicle.
Available Turns: 4.5T, 5.5T, 6.5T, 7.5T, 8.5T, 9.5T, 10.5T, 13.5T, 17.5T, 21.5T,25.5T - 3.5T order by request.
Improvements good Actinium V4 motor:
•Revised construction design for improved sensor accuracy.
•Revised stator dish profile with 3 screws holes sealed to improve magnetic field persistence and effectiveness.
•Traditional three long construction screws replaced with quick screws mounted to part from the end bell.
•Copper wiring purity increased for minimized opposition. Hand injury for optimum precision and effectiveness.
•Revised rotor magnetic item for improved strength, effectiveness and expand the fade out time.
•Motor can machining pages significantly revised from V4 to improve convection cooling.
•Collector band machined from proprietary alloy leading to minimal opposition and maximum temperature dissipation.
