Innovative Double-switch Design
A built-in electronic switch along with an outside detachable switch efficiently assists
the XR10 inventory Spec avoid some flaws of ordinary or one-switch ESCs. The interior switch
makes the wiring convenient, the external switch is truly handy whenever automobile shell is
create on plus the integral switch is no longer touchable.
Special Design for INVENTORY Class Racing
Reliable equipment along side great pc software (contains 5 typical ready-to-use
pages) creates a great power means to fix the STOCK span of 1/10 scale touring car,
buggy battle.
Programming/Upgrading/
information learning Wirelessly
With Hobbywing's "WiFi Express" module and iPhone or an Android os phone (using the HOBBYWING
WiFi Link computer software create), the consumer can from another location system parameters, upgrade firmware and
check relevant information of ESC without making the control stand.
Minimal Size & Light Weight
This ESC is smaller and lighter versus standard version XR10
professional therefore's the mini form of XR10 professional 160A. The tiny size
(31.5x25.6x16.1mm) makes the installation convenient as well as the
light-weight (simply 28g w/o cables) provides more excess weight margin
whenever adjusting the quantity the chassis.
Super Internal BEC
The integral switch mode BEC with a maximum output
of 6A and voltage adjustable between 6V and 7.4V
enables the buyer to work well with various high voltage servos.
Adjustable Throttle & Brake PWM Frequencies
Independent and adjustable throttle & brake PWM frequencies guarantee accurate and accurate
throttle and braking system control for many classes of competitions (esp. the inventory course).
Data-logging Capability
This ESC features the data-logging function which could record
the utmost ESC & engine conditions, the minimum battery pack
voltage, the most engine RPM and an such like. straight away and
enables users to test those information via a LCD program industry or
WiFi module after each and every usage.
Item Specification
Type
- Scale : 1/10th
- Brushed/Brushless : BL
- Sensored/Sensorless : SD
- Waterproof : No
Specifications
- Cont./Peak Present : 80A/380A
- Input Voltage : 2S Lipo/5-7 Cell NiMH
- BEC production : change Mode: 6V/7.4V,3A
Wires & Connectors
- Input Wires : Black-14AWG-200mm*2
- Output cables : Black-14AWG-200mm*3
- Input Connectors : No
- Output Connectors : No
Fan
- Size : 20x20x8mm
- Voltage number : 5-7.4V
- Powered by : BEC
ESC Programing via
- SET Button on ESC : maybe not Supported
- LED Program Box : maybe not Supported
- LCD Program Box : Supported
- WiFi Module : Supported
- Program Port : individual system Port
Firmware
- Firmware Upgrade : Supported
Size & Weight
- Size : 31.5x25.6x16.1mm
- Weight : 54.5g (w/Wires)
Applications
- Motors : SL BL Motors
SD BL Motors - Vehicles : STOCK span of 1/10th Touring automobile & Buggy Racing
- KV Rating/T Count : 1/10th Touring Cars≥10.5T, 1/10thBuggy≥13.5T
