Full-sensored Mode Supported
The very first 1/8 scale competition ESC that may work the full-sensored mode anyway
times (when combining it with a HOBBYWING matching motor).
Turbo Timing Technology
Turbo timing technology is implemented by the XR8 SCT to unleash the utmost energy
of a HOBBYWING matching motor.
Small & Light construction Design
Small (30.1per cent smaller when compared with XR8 Plus in size) and light (36.5g lighter than XR8
Plus in fat) framework design significantly simplifies installing
the energy system (esp. for vehicles like buggy and touring automobile
with compact framework).
Programming / Upgrading /
information reading wirelessly
With Hobbywing's "WiFi Express" module and iPhone or an Android phone (with all the HOBBYWING
WiFi Link pc software installed), the consumer can remotely plan parameters, upgrade firmware and
always check relevant information about the ESC without making the control stand.
Coasting
The XR8 SCT provides a really smooth off-throttle coasting function, which simulates the impression
of inertia and energy of a large-scale automobile driving experience. This might greatly enhance the
performance of builds making use of big, high-powered motors as electromagnetic drag
becomes a considerable factor in unexpected deceleration whenever in off-throttle
position, adversely impacting driving performance and general maneuvering.
Capacitor Thermal Protection
Capacitor thermal protection implemented by the XR8 SCT will efficiently prevent capacitors
from exploding and causing irreversible harm to the ESC because of overload.
Tall Voltage Built-in BEC
High voltage integrated BEC with a manufacturing up-to-date all the way to 15 Amp and a
switchable manufacturing voltage of 6V-7.4V enables users to
use various high torque and high voltage servos.
High Reliability & Durability
Built with the most tough and top-notch elements and in combination with cutting-edge firmware,
the XR8 SCT can deliver unmatched power and satisfaction even the absolute most hardcore
of rushing applications, additionally it is responsive sufficient to shield itself from damage due
to overloading because of genuine abuse, overuse and/or individual mistake.
Advanced and Secure Electronic Switch
Electronic switch with a lifespan of over 50000 on/off cycles, housed in an entirely waterproof,
dust-proof and shock-resistant design.
Ultra-Reliable Cooling System
HOBBYWING's patented air-con technology utilizes proprietary heat-conductive copper
bars to quickly and efficiently go all interior temperature from the MOSFET board towards
integrated CNC machined billet aluminum heatsink housing. The cooling fan adopts a
shockproof mounting which effortlessly reduces the chance
of fan damage considering vehicle’s regular jumps.
Wide applicability
This XR8 SCT ESC isn't only applicable to 1/8th buggies and short-course
trucks but in addition 1/10th short-course automobiles, cars and monster automobiles.
Item Specification
Type
- Scale : 1/8th&1/10th
- Brushed/Brushless : BL
- Sensored/Sensorless : SD
- Waterproof : No
Specifications
- Cont./Peak Present : 140A/880A
- Input Voltage : 2-4S Lipo/6-12 Cell NiMH
- BEC manufacturing : modification Mode: 6V/7.4V,6A
Wires & Connectors
- Input Wires : Red-12AWG-200mm*1/Black--12AWG-200mm*1
- Output Wires : Blue -12AWG-200mm*1
Yellow-12AWG-200mm*1
Orange -12AWG-200mm*1 - Input Connectors : No
- Output Connectors : No
Fan
- Size : 30x30x10mm
- Voltage number : 5-7.4V
- Powered by : BEC
ESC Programing via
- SET Button on ESC : perhaps not Supported
- LED Program Box : perhaps not Supported
- LCD Program Box : Supported
- WiFi Module : Supported
- Program Port : PRG/Fan Port
Firmware
- Firmware Upgrade : Supported
Size & Weight
- Size : 54.1x37.2x36.1mm
- Weight : 90.5g
Applications
- Motors : SL BL Motors
SD BL Motors - Vehicles : 1/10th SCT/Truck/Monster Truck & 1/8th Buggy/On-road Racing
- KV Rating/T Count : With 2S LiPo/6S NiMH: 3660 size engine, KV≤6000
With 3S LiPo/9S NiMH: 3660 size motor, KV≤4000
With 4S LiPo/12S NiMH: 3660 size motor, KV≤3000
With 4S LiPo/12S NiMH: 4268 size motor, KV≤2500.
