XRAY 340007 - Xray RX8.2 - 1/8 Luxury Nitro On-road Car  [XR-340007]

All-new 2018:

• All-new framework features larger front part window starting for enhanced ahead traction
• All-new chassis with exclusive, revolutionary front flex modification making use of a detachable aluminum brace. Using the aluminum brace increases steering reaction and cornering rate; without the aluminum brace, the car is a lot easier to push.
• All-new adjustable weight place on both edges of framework for quick & effortless fat stability adjustment
• All-new straight back layshaft bulkheads allow using bracket bushings so that you can connect the layshaft bulkheads with back bulkheads to fortify the whole straight back suspension system, providing improved managing particularly in high-traction conditions.  Without bracket bushings, the automobile has more traction; suitable for low-traction conditions. The newest bulkhead design additionally permits setting up a top graphite brace.
• All-new back aluminum bulkheads
• All-new graphite brace for straight back layshaft is section of the straight back suspension system Multi-Flex™ Technology
• All-new graphite holders for back top supply have brand new jobs – paid down & more inside – for increased traction and improved durability
• All-new straight back aluminum suspension system system holders have unique destination the back fingers – more inside – for increased traction
• All-new steel extensions for suspension arms have in fact a fresh place to operate better with new back aluminum suspension holders

General

• Developed, produced, and styled by Martin Hudy, manufactured solely by XRAY in European countries on the planet's many sophisticated RC production facility
• Pure rushing design, premium luxury quality, greatest performance
• Premium, exclusive, and high-tech materials used throughout
• Original, super-strong composite materials with XRAY's self-developed secret substance mixtures for suspension and drivetrain components
• Super-low CG 1/8 on-road automobile platform
• Easy-access to drivetrain elements for super-quick rebuilds and set-up changes

Chassis

• Chassis spaces machined at front & straight back of chassis for extra weights

• Chassis design with bigger opening display under front suspension system for better forward traction
• Chassis design enables to install front framework brace in the framework to reinforce the front flex for better steering response
• Aluminum main frame & backbone
• Rear layshaft bulkheads permits to put in the shim which connects the layshaft bulkheads with back bulkheads which reinforces the entire rear suspension system for improved steering and rotation in high traction conditions
• High-precision CNC-machined aluminum bulkheads, suspension system holders, and chassis
• Light & strong help framework with maximum flex faculties for increased traction
• CNC-machined 5mm Swiss 7075 T6 aluminum chassis
• Super-narrow framework increases chassis flex, generates more traction and steering
• Smooth framework underside with countersunk fasteners, chamfered sides to avoid contact during cornering
• Special framework openings machined at front & rear of framework for extra weights
• Strategic chassis cut outs for optimized flex traits, centric engine mount holes for improved flex
• Centerline framework holes are pre-drilled for easy balancing with the HUDY Chassis Balancing Tool #107880.
• CNC-machined Swiss 7075 T6 aluminum bulkheads offer improved stiffness & flex faculties for better steering faculties, offer comfortable access to any or all elements. Incorporated front side & back gear tension adjustment. Incorporated muffler mount in remaining front bulkhead eliminates negative flex impact.
• Aluminum front & back top clamps, developed to fit aluminum bulkheads. Front clamps retain the front side shock tower, front upper arm mount; rear clamps keep back surprise tower, graphite top supply holders.
• Aluminum front top supply holders built to make use of the aluminum bulkheads, and offer optimal flex modification. Easy destination adjustment for increased caster angle and enhanced cornering speed.
• Aluminum center shaft owner developed to use aluminum bulkheads, will behave as belt tensioner for the front & part belts.
• CNC-machined 2.5mm graphite radio dish. Quick & effortless treatment plan for servicing and cleaning.
• Radio meal flex is adjusted on their own from chassis flex, making use of either fixed or flex bushing.
• Radio dish alum mounts are  designed to suit towards aluminum framework. Lightweight mounts give enhanced flex faculties and durability.
• Low-profile 125cc vehicle's gas tank offers for improved gasoline motion, ensuring more stable & constant motor procedure at paid down gas amounts.  Hypertonic tank lid and inside stone-type filter is place in the biggest market of the car and sits just possible
• fuel tank mounting atop the atmosphere dish on alum articles with plastic grommets for simple insertion & decrease from vehicle, permits easy cleansing and maintenance
• Original XRAY vehicle's gas tank uses the well-proven leak-free, super-durable cap through the NT1
• Low-CG battery owner positioned underneath the gas tank. Optional graphite with integrated Multi-Flex Technology™ functionality. Optional metal battery owner adds weight to your base regarding the car.
• Unique compact lightweight radio example with clean design and interior design for receiver and optional on-off switch

Suspension

• Advanced suspension system geometry accuracy engineered and finely tuned for high-competition racing
• Lightweight, durable, and reinforced suspension system parts molded from XRAY's self-developed composite combination for suspension elements. Each suspension system component is molded from a high-tech composite that's specifically developed the particular part.

• CNC-machined Swiss 7075 T6 front & back suspension system system holders, fully split through bulkheads, mounted straight to the framework to enhance traction as well as make the car more straightforward to drive.
• Rear upper supply holders, machined from 3.5mm graphite material for optimized flex characteristics.
• Highly-polished, high-tensile steel suspension system pivot pins give smooth suspension action, feature machined groove for better affixing by setscrew
• I.S.S. (included suspension system Settings™) for completely included adjustment opportunities.
• Full suspension system system modification via square eccentric bushings in the front top and rear upper/lower bulkheads.
• Tiny, tough steering obstructs produced from unique composite combination have actually 0° kingpin (+1° and -1° kingpin steering obstructs suggested). Accommodates graphite aerodynamic disks.
• Aluminum steering block extensions with three Ackermann jobs are mounted towards the steering blocks with two screws
• Small, robust back uprights function two easily-adjustable top roll center jobs for traction adjustment. Uprights function two body mounting adjustment functions to make use of different human body types.  Accommodates graphite aerodynamic disks.
• Concentric & eccentric bushings in-front steering blocks & rear uprights allow simple modification of roll center, caster, wheelbase, and axle height
• Easily-adjustable wheelbase & fat balance and caster modification via positioning clips
• Choice of front anti-roll club systems:  cable or blade-type (both included)
• Front and back cable anti-roll pubs supported by ball-bearings
• Both front cable and blade anti-roll pubs contained in the kit
• Optional front & right back anti-roll bar cables made for fine tuning
• Premium Hudy Spring Steel™ adjustable turnbuckles with rigid core
• Precision-ground metal pivot balls included for robustness and improved lifespan; optional lightweight aluminum and titanium pivot balls available
• Strong M10 composite peanuts for minimal weight and smooth pivot ball movement
• Front steering block & rear uprights function concentric and eccentric bushings which allow roll center modification and good caster modification in-front. Right back upright eccentric bushings allow independent wheelbase & axle height modification.

Motor & Clutch

• Quick-set aluminum engine mount system with fixed motor place for super-easy engine installation and gear mesh adjustment
• Easily-adjustable 3-shoe XCA (XRAY Centrifugal-axial) clutch with 4-bearing clutchbell for superior durability, smooth & fast acceleration, increased clutch footwear lifespan
• Clutchbell, clutch nut, flywheel nut, thrustbearing collar made of unique HUDY Spring Steel™ for maximum lifespan and durability
• Hardcoated flywheel, clutch dis, spring cup manufactured from premium Swiss 7075 T6 aluminum
• Clutchbell / pinion gear construction allows super-precise assembly
• Swiss 7075 T6 machined pinion gears, particularly created for 1/8 on-road, for significantly improved durability and strength. Pinion gear teeth are separately machined on a high-precision gear manufacturing unit; special hardcoating ensures optimum life
• Carbide axial thrust-bearing and high-tensile spring
• Small diameter aluminum flywheel improves the engine bottom energy and acceleration

Brakes

• Strong, highly-efficient braking system system
• Laser-cut, precision flat-ground ventilated metal braking system disk with extra-deep machined grooves for light-weight and exceptional heat dissipation, maximum stopping efficiency and super-smooth stopping action; strategically-placed air flow holes ensure minimal braking system pad use and super-true, wobble-free rotation
• Brake disk and stopping system backing pads are heat-treated for maximum performance and lifespan
• Special return softer springs guarantee appropriate gap between braking system pads
• CNC-machined metal stopping system cam is ball-bearing supported for super smoothness and accurate braking system control

Drivetrain

• Smooth and efficient 1/8 on-road drivetrain
• Ultra-smooth, highly-efficient belt/pulley drivetrain with super-low rotating mass
• Front center shaft owner offers simple front gear & pulley access and easier maintenance
• Exclusive using HUDY Spring Steel™ in drivetrain components provides best performance and unmatched lifespan
• High-performance HUDY Spring Steel™ front CVD drive shafts; rear dogbone-style HUDY Spring Steel™ drive shafts
• Super-lightweight wheel axles & axle outdrives are CNC-machined from HUDY Spring Steel™
• PUR®-reinforced high-efficiency, low-friction, fine-pitch drive belts
• Pulleys molded from super-low friction composite product for extra-long lifespan, pulley covers function self-cleaning holes
• Complete group of high-speed, blue-sealed ball-bearings, degreased, gently oiled with Aero Shell Fluid 12™ for optimum drivetrain efficiency
• Graphite side-belt tensioner made to take advantage of alum framework. Simple gear adjustment, simple therapy.

2-Speed Transmission

• Superior, robust 2-speed transmission with small & light gears, excellent bottom-end energy & acceleration
• Small & lightweight gear carrier, aluminum drive flange with 1-way bearing
• Small & lightweight gears from well-proven NT1 for fast acceleration and low rotating mass
• Gears from graphite product within the kit for improved durability from the transmission
• Precision-manufactured, super-smooth lightweight hollow center layshaft made from tough HUDY Shaft metal, specifically heat addressed for additional power and long life
• High-quality 1-way bearing hand-ground for maximum running precision and strength
• 2-speed spur gear adapter CNC-machined from Swiss 7075 T6 for precision fitment of 1-way bearing, allowing super-precise and wobble-free spur gear installation
• World's many exact spur gears molded from unique composite combination guarantees wobble-free operating and eliminates run-out
• 2-speed gearbox footwear molded from unique composite mixture

Axles

• Front super-lightweight one-way axle created from Swiss 7075 T6 alum for super-low rotating mass and low CG
• Rear axle made from HUDY Spring Steel™ with composite lightweight axle pulley
• One-way outdrives made of HUDY Spring Steel™ and especially ground for maximum precision

Steering

• Centralized servo saver is ball-raced for super-precise, smooth operation
• Adjustable springtime preload tension
• Easily-changed Ackermann positions

Shocks

• Shock pistons with 2- and 3-hole designs and 1.0/1.1/1.2mm holes, produced from unique Delrin™ product to make sure extreme roundness and extra-smooth damping
• CNC-machined shock numbers produced from Swiss 7075 T6 aluminum, externally fine-threaded for precise journey height adjustment
• Low-profile inside membranes for super-smooth, exact damping
• Specially-hardened surprise shafts for optimum strength
• XRAY self-developed and produced battle springs are hand-selected and tested for maximum accuracy, equal size, and equal damping characteristics
• Compact front & right back CNC-machined graphite surprise towers

• XRAY Premium Silicone oils are included. Stated in Europe by a specialized premium silicone oil manufacturer, each batch of premium oil is laboratory tested and calibrated to guarantee the highest possible determination and quality batch-to-batch. In line with the industry-standard cSt rating.

Body & Wheels

• Optional CNC-machined high-strength graphite aerodynamic disks improve both low & high-speed steering, enhance right back traction, and enhance safety in high-speed corners.
• Front human body articles, CNC-machined from Swiss 7075 T6 alum, in addition lightened for minimal fat.
• Special composited back human body mount features 3 roles for right back upright downforce adjustment.
• Tough composite right back body mount owner permits mounting of all of the popular sporting numbers and satisfies all EFRA / IFMAR rules.

Assembly & Support

• Premium 3D full-color guidelines is included
• Comprehensive Set-up Book can be had on the web as a free of charge download
• Exclusive Virtual on the web Set-up Sheet database with numerous of set-up sheets for battle songs around the world
• Premium, unmatched XRAY on the web support

Adjustment Possibilities

• Fully-adjustable front side and straight back suspension system geometry: caster, camber, toe, journey height, droop, wheelbase, track-width, roll facilities, axle height, wheel offset
• XRAY Multi-Flex Technology™ allows fast & effortless framework and radio dish tightness adjustment
• Adjustable front side & straight back roll centers
• Adjustable gear stress via bulkhead inserts, part gear tensioner, front center shaft owner position
• Adjustable HUDY Spring Steel™ turnbuckles (steering, servo, right back top links)
• Adjustable Ackermann positions
• Front & right back top and reduced surprise mounting locations
• Adjustable aluminum rushing shocks
• Adjustable front anti-roll bars, blade or cable type
• Adjustable wire-type rear anti-roll bar
• Adjustable weight balance
