Effective Hardware for extremely fast working Speed
The STM32F405 MCU, which features effective computing ability & super operating rate,
with the high-sensitivity ICM20602 6-axis movement sensor supports 32KHz PID controller &
gyro. The integral OSD chip allows users to modify or set OSD parameters through
Betaflight/Cleanflight/Butterflight/invaflight pc software or transmitter effortlessly. The inside TF-card
expansion slot permits users to position a SD card to record more trip information.
Revolutionary Shock-absorbing Structure
The Innovative linking method via a soft cable (*it increases results
whenever pairing because of the XRotor Micro 45A 4in1 BLHeli_32 DShot1200)
coupled with shock-absorbing design of mounting holes
effectively reduces the affect high-sensitivity FC elements
from outside surprise to create every journey more stable and accurate.
On-board Filter Circuit
The XRotor Micro-F4-G2, which integrates with a filter circuit
module (*it just functions whenever pairing with the 10V BEC regarding the
XRotor Micro 45A 4in1 BLHeli_32 DShot1200), provides purer
powering condition for VTX to help make photos more clear and stable.
Several Throttle Signal
Modes Supported
Besides the most recent DShot 150/300/600/1200
high-speed electronic throttle sign modes and also the
Proshot1000 blended throttle sign mode, the
Oneshot125/Oneshot42/Multishot and regular PWM
throttle sign modes may also be supported.
Multiple FPV Firmware Supported
The XRotor Micro-F4-G2 not merely supports many conventional FPV firmware like BetaFlight, Cleanflight,
Butterflight and invaflight, but in addition allows users to modify or set parameters through the matching
software. All of this makes the machine more highly relevant to different FPV roads & race.
Compatible(with the Hobbywing 4IN1 ESC&VTX)
It’s very easy to wire and install whenever combining the FC with a Hobbywing 4-in-1 tower ESC & a HOBBYWING VTX (movie Transmitter).
Item Specification
Basic Features
- Compatible with (Multirotors) : Quadcopter
- Firmware : OMNIBUSF4SD
- FC Programming : Supported
- Programming via : Betaflight/Cleanflight-configurator or Others
- Compatible with (Modes) : PWM, Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300,
Dshot600, DShot1200, Proshot1000 and etc. - suitable for (Transmitters) : PPM, Spektrum, SBUS, SUMD, SUMH, XBUS, IBUS, JETIEXBUS, CRSF, SRXL, and etc.
- OSD : Built-in
- Voltage Monitoring : Supported
- Current Monitoring : Supported
- External Buzzer : Supported
- LED Control : Supported
- BEC : No
- USB Port : MicroUSB
Size & Weight
- Size : 36*36mm
- Weight : 6g
